Image preview - the first page of the document
>> Download 5103R-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. 5103R
New Tool
Description 270 mm (10-5/8") Circular Saw
CONCEPTION AND MAIN APPLICATIONS
Model 5103R is a redesigned version of the existing
Model SR2600.
It is equipped with a riving knife, larger base, more
efficient chip/sawdust ejection port, soft-start feature,
)
electric brake, etc.
322mm(12-11/16"
Guide rail and guide rail adapter are available as
2")
(12-15mm
optional accessories.
13/3
Model 5103R complies with CENELEC Standard.
3
It is offered to European countries and areas only.
Specifications 442mm(17-13/32")
Continuous Rating (W)
Voltage (V) Current (A) Cycle (Hz) Max. Output(W)
Input Output
100 15.0 50/60 1,430 800 2,400
110 20.0 50/60 2,100 1,250 2,400
(for U.K.)
115 15.0 50/60 1,650 900 2,400
220 10.0 50/60 2,100 1,350 3,300
230 9.6 50/60 2,100 1,350 3,300
240 9.2 50/60 2,100 1,350 3,300
Blade diameter 270 mm (10-5/8")
Arbor diameter 30 mm (1-3/16")
Max. cutting capacities At 90 100 mm (3-15/16")
At 45 73 mm (2-7/8")
No load speed 3,800R/min
Net weight 9.4 kg (20.7 lbs)
Standard equipment
Rip fence (guide rule), Hex wrench 6, Carbide-tipped saw blade 270
Optional accessories
Carbide-tipped saw blade 270, Joint set, Guide rail, Guide rail adapter
Features and benefits
1. Double insulated
2. For further information, see information sheet which we will send you later.
The standard equipment for the tools shown may differ form country to country
Electric brake and soft-start
features for more efficient
operation
Large ejection port for smooth
chip/sawdust outflow;readily Less noise than FESTO AP85E
accepts joint for dust collec- 5103R :85db
tion AP85E :85db
Sturdy aluminum base and angular
guides for smooth cutting
Adjustable top guide for align-
ing the cutting line
marking to indicate the
front edge of saw blade
Rollers for smooth, scratch-free
action over surface of material
Graduations for depth of cut
Hex wrench can be stored here
Handy carrying handle
Easy-to-operate lever for
adjusting the depth of cut
Flat surface for easy replace-
ment of blades
Guide rail adapter is available
as an optional accessory.
MAKITA or FESTO guide rail can
Peep window to check if blade be used with this guide rail
edge is aligned with cutting adapter.
line.
Motor cooling air passes through
this peed window and blows away
sawdust around cutting line
