Image preview - the first page of the document
>> Download 52563-ww-1 documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION 52563
Subject Change of Joint,Lever,Screw and addition of Hex.Sleeve
For Models 4304T,4305T(JIG SAW)
Description Hex.Sleeve has been added to be inserted to be inserted into Joint to increase strength of
Joint.
Only for Model 4304T,Pan Head Screw M4x8 fixing Lever 51 has been changed to
Countersunk Head Screw M4x6. Accordingly the Lever 51 has been changed.
Current New
Change of Joint and 10mm 11mm Hex.Sleeve
Addition of Hex.Sleeve
Joint
Pan Head Screw M4x8 Countersunk Head Screw M4x6
Change of Lever 51 and
Screw (only for 4304T)
Lever 51
Interchangeability(I/C)
Item No. Current part Q'ty I/C New part Q'ty Note
Joint Joint
36 415882-1 1 No 416351-5 1
Hex.Sleeve Interchangeable as a set
90 1 1
344537-0
Lever 51
3 1 No Lever 51 1
415881-3 416370-1 Interchangeable as a set
Pan Head Screw M4x8 for 4304T
1 1 No Countersunk Screw M4x6 1
911109-2 912102-9
Implementation
4304T : From September,96
4305T : From September,96
