Image preview - the first page of the document
>> Download 55903-WW-1 documenatation <<
Text preview - extract from the document
TECHNICAL INFORMATION
Subject Change of Grip 36 Complete
55903
For Models HP1210, HP1500, HP1510, HP2030, HP2031, HP2040, HP2041, HP2042, HR2410, HR2042
(except machines manufactured in U.K.)
Country All countries
Description As described below, material of Grip 36 complete has been changed.
Material is inscribed here.
Current New
Material PP-GF20 ABS
Interchangeability(I/C)
Item No. Current part Q'ty I/C New part Q'ty Note
HP2030: 033 Grip 36 Complete 1 Grip 36 Complete 1
Yes
HP2031: 033 152489-9 152521-9
HP2040: 050
HP2041: 050
HP2042: 050
HR2410: 045
HR2420: 053
Implementation
HP2030 : From serial No.35990E (May, 1998)
HP2031 : From your next order in/after July, 1999
HP2040 : From serial No.38085E (Apr., 1998)
HP2041 : From serial No.17926E (Apr., 1998)
HP2042 : From serial No.11028E (Apr., 1998)
HR2410 : From serial No.249638E (Apr., 1998)
HR2420 : From serial No.6901E (Apr., 1998)
