5600RD-TE


>> Download 5600RD-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.           5600RD(5600RDW)
                                                                                                    Product


        Description          160 mm Cordless circular Saw

CONCEPTION AND MAIN APPLICATIONS




                                                                          222mm
   To enrich the battery tool series, to widen their applications
   and to reply to the demands from market, the cordless circular
   saw with riving knife has been developed mainly for use in fitting.
   The 5600RD(160 mm battery circular saw) and DC1000
                                                                                                                 m
   (Fast charger) are combined into the one model called                                                    4m
                                                                                                       17
   5600RDW.                                                            25   7m
                                                                                  m
    Specifications
     Motor                                  DC Magnet Motor
     Voltage (V)                                  10.8
     Current (A)                                  18
                       Input (W)                 190
     Continuous Rating Output (W)
                                                 100
     Max.Output (W)                              115
     No Load Speed (rpm)                       1,000
                 Diameter (mm)                   160
     Saw Blade Arbor Diameter (mm)                 20
                Thickness (mm)                      1.45
     Cutting Capacity At right angle                0 - 55mm
                      At 45
