Image preview - the first page of the document
>> Download 5704R-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. 5704R, 5704RK
PRODUCT
P1/8
Description L-1
Circular Saw 190mm
L-2
CONCEPTION AND MAIN APPLICATIONS
Model 5704R has been developed as the 190mm Circular Saw H-2
with riving knife.
This easy-to- control Circular Saw also features its superiority H-1
to competitors in Low noise, Low vibration and Cutting speed.
Save more money, and get higher performance.
Model 5704RK comes with plastic carrying case.
See next page for more information.
Dimensions : mm (") W-1
W-2
Length (L-1) 345 (13-5/8)
Length (L-2) 328 (12-7/8)
Height (H-1) 253 (10)
Height (H-2) 181 (7-1/8)
Width (W-1) 238 (9-3/8)
Width (W-2) 150 (5-7/8)
Specification
Continuous Rating (W)
Voltage (V) Current (A) Cycle (Hz) Max. Output(W)
Input Output
110 12 50 / 60 1,200 740 1,400
220 5.3 50 / 60 1,100 610 1,100
230 5.5 50 / 60 1,200 740 1,400
240 5.3 50 / 60 1,200 740 1,400
No load speed : rpm.= min.-1 4,900
Size of blade Diameter : mm (") 190 (7-1/2)
Arbor : mm (") 30 (1-3/16) * 20 (13/16) for China
Max.cutting at 90◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
