Image preview - the first page of the document



>> Download 57575-WW-1 documenatation <<

Text preview - extract from the document

T ECHNICAL INFORMATION
 Subject                Elimination of Positive Stop Function
                                                                                                                57575


 For Models             BO5010, BO5011
 Country                All countries
 Description            As illustrated below;
                        1) Depressions for positive stop have been eliminated from Skirts (L) and (R).
                        2) Two Leaf Springs for positive lock have also been eliminated,
                           and replaced by one O Ring 75.

                          Current                                                             New




  Leaf Spring                                                        O Ring 75
  (Part No.232166-0)                                            (Part No.213755-0)


                                                    Skirt (L)                                                     Skirt (L)




   Skirt (R)                                                       Skirt (R)




Interchangeability(I/C)

   Item No.             Current part              Q'ty I/C            New part               Q'ty            Note
BO5010: 011, 032      Skirt Set                                 Skirt Set                     1     Skirt Set includes
                                                    1
BO5011: 013, 034      182922-7                                  183088-6                            Skirt(R) and Skirt(L).
BO5010: 010           Leaf Spring                               O Ring 75                     1
                                                    2
BO5011: 012           232166-0                                  213755-0

 Note
1) Interchangeability mark ;         means that the current part is substituted for the new.
2) It is also possible to use the new Skirt Set or O ring 75 for repairing the current type of machine.
   In this case, however, the positive stop function is lost after repairing.

 Implementation
BO5010 : From serial No.71837A (Dec.,1998)
BO5011 : From serial No.5033A (Feb.,1999)
