TECHNICAL INFORMATION
Subject Modifications of Switch and Slide Cover
58559A
For Models 9035KB, 9045B, 9045N
Country All countries (See the column of Interchangeability for detailed information.)
Description As illustrated below, Switch has been changed for more developed dust-proof structure.
Slide Cover has also been changed in accordance with the addition of polyester sheet on switch.
Current New
polyester sheet
adhesive
Switch
tape (thickness: 0.2mm)
Sheet, adhesive and tape as dust-proof devices
2.0mm
2.3mm
Slide Cover
protrusion inscription of "N"
for distinction
Interchangeability(I/C)
Item No. Current part Q'ty I/C New part Q'ty Note
9035KB: 034 Switch SS106AY Switch SS106AY 1 Countries of Group 1) :
1 No
9045B: 008 651602-1 651607-1 Near and Mid. East countries,
9045N: 008 African countries (except
9035KB: 032 Slide Cover S. Slide Cover 1 South Africa), Cyprus, Greece,
1
9045B: 006 652152-9 652190-1 Asian countries (except China
9045N: 006 and Hong Kong), Tonga,
Western Samoa, South and
Central American countries
9035KB: 034 Switch SS203KY-3 Switch SS203KY-3 1 Countries of Group 2) :
1 No
9045B: 008 651653-4 651656-8 European countries (except
9045N: 008 Cyprus and Greece),
9035KB: 032 Slide Cover D. Slide Cover 1 South Africa,
1
9045B: 006 652153-7 652191-9 Oceanian countries (except
9045N: 006 Tonga and Western Samoa)
China, Hong Kong,
U.S.A., Canada, Mexico
Switch
Current New
recommendable must not be used together Note)
Slide Cover Current Always use the new Slide Cover
New recommendable recommendable
for the new Switch.
Note
Interchangeability mark ; means that the new part is substituted for the current.
Implementation
9035KB : Countries of Group 1) ; To be informed later
Countries of Group 2) ; To be informed later
9045B : Countries of Group 1) ; From serial No.183653E (June, 1999)
Countries of Group 2) ; From serial No.183929E (June, 1999)
9045N : Countries of Group 1) ; From serial No.213738E (June, 1999)
Countries of Group 2) ; Mexico / From serial No.213378E (May, 1999),
Other Countries / From serial No.213618E (June, 1999)
