TECHNICAL INFORMATION
Subject                 Addition of Gear Complete Repairing Set
                                                                                                             60167


For Models              6409, 6410

Country                 All countries

Description             To prevent the chuck from wobbling after replacing Gear Complete, Gear Complete Repairing
                        Set (including Steel Ball 3.5 and Pin 4) has become available.

                        Current                                                            New
                                                                             Gear Complete Repairing Set
                 Gear Complete                                              (including Steel Ball 3.5 and Pin 4)


                                Steel Ball 3.5


                                            Pin 4




Interchangeability(I/C)
Item No.         Current part              Q'ty I/C             New part                   Q'ty             Note
           Gear Complete                               Gear Complete Repairing Set
    009                                     1                                               1
           153245-0                                    193050-3
           Steel Ball 3.5
    007                                     1
           216001-0
           Pin 4
    006                                     1
           256251-5


Note
Interchangeability mark ;        means that the new part is substituted for the current.

Implementation
Ready to receive your order since Jan., 2000
