Image preview - the first page of the document
6019D-TE


>> Download 6019D-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
Models No.                 6019D,6019DW
                                                                                                                    New Tool


Description              10 mm Cordless Driver Drill

CONCEPTION AND MAIN APPLICATIONS
   Model 6019D which has clutch for setting fastenig torque                                         251mm(9-7/8")
   in addition to Model 6018D is redesigned version of
   existing Model 6075D.
   Its breief benefits are;




                                                                              215mm(8-1/2")
   *Easy operation
    by ergonomic design for easily pushing the axis of
   *Very quiet
   *Setting of fastening torque : 10 stages + drill-mode
   *Equipped with an electric brake
                                                                                              56mm(2-3/16")
                     Speed           Drill                       Fast
      Model                                        Battery     charger
                    control         chuck
      6019D         2 speeds                        N/A          N/A
                       +
                    variable        Keyless        Battery     DC9700
     6019DW
                      speed                         7000      or DC7l00

   Specifications
   Motor                                            DC 7.2V magnet motor
   Battery                                          Battery 7000 (Ni-Cd,7.2V,l.3Ah)
   No load speed                                    H:0-600rpm L:0-200rpm
   Chuck capacity                                   1. 0-l0 mm (l/32-3/8")
   Capacities              Steel                    10 mm (3/8")
                           Wood                     15.4mm (5/8")
                           Wood screw               5. l mm (13/64") X 35 mm (l-3/8")
                           Machine screw            M6
   Max. fastening                            H      Approx. 40Kgf.cm(35in. lbs)
   torque                                    L      Approx. l20Kgf.cm(l04in.lbs)
  Net weight                                        1.1Kg(2.4lbs)
  (including battery)
                                L : Low speed          H : High speed
  Standard equipment
                                  60l9D      60l9DW
   +- Bit 2-45 (2 pcs.)                   Yes
   Battery Cover                    No         Yes
   Plastic Carrying Case            No         Yes


  Optional accessories
    Drill Bit 1.5,2,3,4,5,6              Drill Bit for wood 9,12,15
    Philips Bit l-65,2-45,2-65,2-82,2-ll0,2-150,2-250,3-45,3-65,3-ll0
    Slotted Bit 5-45,5-82,6-70,6. 35-45,8-45,8-70
    Socket Bit 5.5-55,7-55,8-55
    Foam Polishing Pad 125                Rubber Pad Assembly          Wool Bonnet 100
    Fast Charger DC7l00,DC9700,DC1201,DC1209                   Automotive charger DC7112

  Features and benefits
   See the attached sheets for more information.

The standard equipment for the tools shown may differ form country to country
                                           2 speeds by gear change (slide-button)

                      Keyless chuck




                                                                                       Ergonomic design
                                                                                       for easilly pushing axis of drilling


                   Setting of fastening torque
                   10 stages + drill-mode



                                                                                                Bit holder
                                                                                                Bits can be held
                                                                                                 at both right and left sides.



                                  Very quiet
                                  6019D : 67dB (total noise of forty 6019's=noise of one 607 5D)
                                  6075D : 83dB


Fastening torque by setting TorqueAdjusting Ring


    Capacity
    1. Reference values of the adjusting position for the fastening torque switch ring and the fastening torque
       (Clutch operation torque)



                       (104.2)
                                                                                                                 Low speed
                         120
                      (86.8)
                        100

Fastening torque        (69.5)
                          80

                        (52.1)
                             60
                       (34.7)
                         40                                                                                      Hight speed
        (in-lbs)
                       (17.4)
                         20
        [kgf-cm]


                         0
                                                 (1)    (2)         (3)       (4)         (5)          Drill-mode

                                             Position of Torque Adjusting Ring

    2. Work volume per charging
       Same as the one for the 6172D.
Repair
(1) Cautions in disassembling --- same as 6018D.
                                                                                                   Place the leaf spring
(2) Cautions in assembling                                                                       in the dent portion.
  1.Assembling of motor and gear assembly --- same as 6018D.                                                  Leaf spring
  2.Assembling of leaf spring                                            Housing L
 Grease in the groove of housing L as shown
 on the right figure to prevent the leaf spring                                              Greasing
 from being dropped in
                                                                                             Figure 1
  assembling.
 Assemble the leaf spring on the housing L as shown
                                                                        Spring holder                      Change ring
 on the figure 1.                                                                   Gear case B
 3.Assembling of change ring
                                                                                              Turning direction
1) Fasten in a way that the edge of spring holder is
                                                                                              of spring holder
   placed by 1 mm or more at inner side apart from
   the edge of gear case B.
2) Assemble so that the change ring can be positioned
                                                                       1 mm or more
   in a straight line.
                                                                                             Edge of Gear case B
 4.Assembling of speed change lever--- same as 6018D
                                                                                           Edge of spring holder
 5.Assembling on the housing --- same as 6018D.
 6.Assembling of drill chuck --- same as 6018D.(Set the change ring to the drill mode.)



Circuit    drawing




                                                                                  Red mark
                                                       Red
                T+
             Terminal                   Switch
                T-                                                                 DC motor
                                                      Black
