Image preview - the first page of the document
60300-WW-1


>> Download 60300-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Elimination of Rubber Pin 4 (a component of Bracket Complete)
                                                                                                         60300


For Models            1100
Country               All countries
Description           As illustrated below, Rubber Pin 4, a component of Bracket Complete has been eliminated.
                      And accordingly, Bracket Complete has been replaced by Bracket which does not include
                      Rubber Pin 4.

                          Current                                                    New

                                  Rubber Pin 4                                  Rubber Pin 4 has been eliminated.
                                  (263002-9)




                      Bracket Complete                                 Bracket
                      (152191-4; includes Rubber Pin 4)                (312246-9; without the hole for Rubber Pin 4)




Interchangeability(I/C)
Item No.        Current part            Q'ty I/C            New part                   Q'ty           Note
    020    Bracket Complete               1   Yes    Bracket                             1
           152191-4                                  312246-9
           Rubber Pin 4                                                                       a component of
    032                                   1
           263002-9                                                                           Bracket Complete



Implementation
From serial No.803074E (Dec.,1999)
