60301-WW-1


>> Download 60301-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Addition of Gasket
                                                                                                         60301


For Models            9040L, 9047, 9047L, 9047S, 9049, 9049S, 9057, 9057S, 9059, 9059S
                      9060L, 9067, 9067L, 9067S, 9069, 9069S, 9617, 9617L
Country               All countries
Description           One Gasket has been added between Gear Housing and Bearing Box as illustrated below.




                Gear Housing                          Gasket
                                                        Part No.              For Models
                                                                   9040L, 9047, 9047L, 9047S, 9049,
                                                        442129-0
                                                                   9049S, 9057, 9057S, 9059, 9059S
                                                                   9060L, 9067, 9067L, 9067S, 9069,
                                                        442124-0
                                                                   9069S, 9617, 9617L
                 Bearing Box

Interchangeability(I/C)
Item No.      Current part            Q'ty I/C       New part                 Q'ty               Note
                                                 Gasket                              For 9040L, 9047, 9047L, 9047S,
                                                                               1
                                                 442129-0                                9049, 9049S, 9057, 9057S,
See below                                                                                9059, 9059S
                                                 Gasket                              For 9060L, 9067, 9067L, 9067S,
                                                                               1
                                                 442124-0                                9069, 9069S, 9617, 9617L

Item No.
 Part No.
             9040L: 048, 9047: 050, 9047L: 050, 9047S: 051, 9049: 050,
 442129-0
             9049S: 051, 9057: 050, 9057S: 051, 9059: 050, 9059S: 051
             9060L: 040, 9067: 044, 9067L: 044, 9067S: 045, 9069: 044,
 442124-0
             9069S: 045, 9617: 053, 9617L: 053

Implementation
Machines manufactured in Japan                              Machines manufactured in U.K.
9040L : From your order received by us in/after Apr.,2000   9040L : From your order received by us in/after Apr.,2000
9047 : From serial No.49448E (Feb.,2000)                    9047 : From serial No.12019G (Feb.,2000)
9047L : From your order received by us in/after Apr.,2000   9047L : From your order received by us in/after Apr.,2000
9047S : From serial No.4456E (Mar.,2000)                    9047S : From serial No.9943G (Feb.,2000)
9049 : From serial No.62459E (Feb.,2000)                    9049 : From serial No.94150G (Feb.,2000)
9049S : From your order received by us in/after Apr.,2000   9049S : From serial No.70664G (Feb.,2000)
9057 : From serial No.10954E (Feb.,2000)                    9057 : From your order received by us in/after Apr.,2000
9057S : From your order received by us in/after Apr.,2000   9057S : From serial No.2484G (Feb.,2000)
9059 : From serial No.38939E (Feb.,2000)                    9059 : From serial No.9163G (Feb.,2000)
9059S : From your order received by us in/after Apr.,2000   9059S : From serial No.13775G (Feb.,2000)
9060L : From serial No.3566E (Feb.,2000)
9067 : From serial No.27151E (Feb.,2000)                    Machines manufactured in China
9067L : From serial No.32091E (Feb.,2000)                   9060L : From Nov.,2000
9067S : From your order received by us in/after Apr.,2000   9067 : From serial No.16121K (Mar.,2000)
9069 : From serial No.108676E (Feb.,2000)                   9067L : From your order received by us in/after Apr.,2000
9069S : From your order received by us in/after Apr.,2000   9067S : From June,2000
9617 : From serial No.2030E (Feb.,2000)                     9069 : From serial No.100539K (Mar.,2000)
9617L : From your order received by us in/after Apr.,2000   9069S : From serial No.28970K (Mar.,2000)
