Image preview - the first page of the document
60665-WW-1


>> Download 60665-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Modifications in Handle Base
                                                                                                              60665


For Models            HM1800
Country               All countries
Description           In order to improve Handle Base and Gear Housing Cover in durability against
                      Compression Spring 12, Handle Base has been modified as described below.

                    Handle Base
             (No.042 in the exploded view
                    of HM1800)
                                                                    1. Side Handle
                                                                    2. Compression Spring 12
                                                                    3. Rubber Sleeve
             1                                                      4. Gear Housing Cover

                                                        4
                                                                    Note:
                                             3                      Another Handle Base (No.094 in the exploded view)
                                      2                             has been replaced by the new one at the same time.


                   Current                                                        New
 [View from the side of Gear Housing Cover]



                                                                               See below for detailed information
                                                                               on modifications.


              Part No.322847-5                           Part No.324062-7

 [Cross Section]
    1                       2                                                Modifications:
                                                                             1) The surface that contacts with the top of
                            3                                                   Compression Spring 12 has been enlarged
                                                                                (See the encircled area in Cross Section.)
                            4                                                   in order to disperse more effectively
                                                                                the spring's tension power against
                                                                                Gear Housing Cover.

                         1. Side Handle                                      2) The way of heat treatment has been
        Handle Base      2. Compression Spring 12                               changed for more durable surfaces that
                         3. Rubber Sleeve                                       receive Compression Spring 12.
                         4. Gear Housing Cover

Interchangeability(I/C)
Item No.       Current part                 Q'ty I/C          New part                     Q'ty           Note
    042    Handle Base                       2         Handle Base                          2
    094    322847-5                                    324062-7

Note
Interchangeability mark ;        means that the new part is substituted for the current.

Implementation
From serial No.18055E (Mar.,2000)
