60787-WW-1


>> Download 60787-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Modifications of Parts Concerning "Motor Head Lock" Function
                                                                                                                60787

For Models              BLS820, LS800D
Country                 European countries
                        Algeria, Reunion, South Africa
                        China
Description             For smoother action of Rod 8 when locking/unlocking motor head;
                        1) Stop Ring E-6 has been added.
                        2) Rod 8 has been modified to accept Stop Ring E-6. (Its part number remains unchanged.)
                        3) A rib to support Rod 8 has been made on Blade Case. (Its part number remains unchanged.)
1) Addition of Stop Ring E-6                             2) Modification of Rod 8
                                                              Current                                   New
                                                                                                   A groove has been made
                                                                                                   to accept Stop Ring E-6
                         2

                   1

                                   1. Stop Ring E-6
                                      (961012-7)
                                   2. Rod 8                                                             Stop Ring E-6
      3                            3. Blade Case

3) Modification of Blade Case
                        Current                                                       New
 View from the rear of Motor Housing
    Blade Case
                                                                                               Rib additionally made



                                                                                           A



                                                                                                   Hole for Rod 8
    Motor Housing


                                                                            Rib (view from "A")

Interchangeability(I/C)
Item No.         Current part             Q'ty I/C           New part                      Q'ty             Note
  E08                                                 Stop Ring E-6                            1
                                                      961012-7
           Rod 8                                      Rod 8                                             Interchangeable
  E03                                       1                                                  1
           323907-6                                   323907-6                                               as a set
    039    Blade Case                       1   No    Blade Case                               1
           183097-5                                   183097-5

Note
1) Interchangeability mark ;     means that the new part is substituted for the current.
2) The current Rod 8 and Blade Case have been discontinued.
3) Each part number of Rod 8 and Blade Case remains unchanged.

Implementation
BLS820 : From serial No.2222E (Mar.,2000)
LS800D : From serial No.1019E (Mar.,2000)
