Image preview - the first page of the document
6073D-TE


>> Download 6073D-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
          Models No.              6073D,6073DW
                                                                                                                   New Tool


          Description             MAKITA Cordless driver drill

CONCEPT AND MAIN APPLICATIONS
Just like 6093D, this cordless driver drill is driven with 7.2 V                        58mm
battery
 1. The torque can adjusted in 12 steps.
 2. Two speed mechanical change.
 3. Variable control switch.
 4. Electric break




                                                                                                           223mm
 5. Over current relay


 6073D is the model No. without battery & charger.
 6073DW is the model No. without battery & charger.




                                                                                          m
                                                                                   255m

    Specifications
     Voltage(V)         Current(A)        Frequency(Hz)      Consumed         Rated            Max.
                                                             power(W)         output(W)        output(W)
           7.2                -                  -                  -               -                -

     Motor                                            DC 7.2 V magnet motor
     No load speed                High                0-850/min
                                  Low                 0-300/min
     Chuck capacity                                   1.5-10 mm
                                  Wood                15 mm
     Drilling capacity
                                  Steel               10 mm
                                  Wooden screw        5.1 x 35
     Screwing capacity            Small   screw       6 mm
                                  Nut                 6 mm
     Max. fastening torque                            80kg-cm
     Net weight                                       1.45 kg (Battery included)



    Standard equipment
      Chuck key S10 --- One piece
      Steel case Bit 2-65 --- One piece    (Only for 6073DW)


    Optional accessories
     Battery 7000
     Fast ChargerDC7012(automotive)
     Please reffer General Catalogue
     for other accessories.



     The standard equipment for the tools shown may differ form country to country
Features and benefits
 (1) The torque can be adjusted in 12-step.[Each 6-step for both high/low speeds]
 (2) Since the switching of the torque can be adjusted at the edge(changing ring) of the machine, changing
     adjustment can be easily done with visible condition.
 (3) The 2-speed mechanical change provides the excellent working efficiency for screwing and drilling.
 (4) The non-step variable speed switch enables to position the wooden screw or drill easily and the best rotation for
     the application can be selected.
 (5) Electric break allows to stop the operation at the desired position, thereby
     enabling easy screwing.
 (6) The overload protector(auto return type) is mounted for protecting the motor and switch from overload.
 (7) The body weight including the battery is 1.45 kg, lighter than 6093D(1.7 kg).
 (8) The RPM in high speed is 0-850/min., higher than 6072D, thereby enabling the higher working efficiency.
 (9) The relief corner just above the switch, for hanging the fingers, and the constricted handle allows to hold the
     machine in well balance and to control the switch in well manner.
(10) The 6073DW with steel carring case.

Capacity
  1) Torque & Torque position chart
     For comparison, the torque for 6093D is shown. The torque are the ones when the new
     clutch cam is used.(Other than the drill position, the clutch may be worn out through using, thereby the fastening
     force is deteriorated by 20 % around.)


                       120

                       100

                       80
                                                             6093D
                                                                          }   Low
                                                                              speed
       Torque(kg.cm)




                       60                                         6073D

                       40
                                                  6093D                   } High
                                                                            speed
                                                                 6073D
                       20



                             1   2    3          4           5             Drill
                                     Torque position

   2) Adjusting position for the fastening force switching ring and the work capacity
      The below table shows the work capacity for each adjusting position expressing in the nominal diameter of
      screw and the drill diameter. Since they may vary depending on the material, it is only for reference.
Applications                     Speed            Adjusting position for torque
                                      mode           1         2          3         4       5       Drill
             Small      screw High                  M4                   M5                         (Note 2)
Screw
                                 Low                M5                   M6
fastenin
             Wooden screw High                                           3.1       3.5     4.1         4.5
g
                                 Low                3.1                  4.5               5.1         5.1
             Steel               High                                                                15-10
                                 Low                                                                Same as
Drilling                                                        Use in drill mode                   above
             Wood                High                                                                   9
                                 Low                                                                 12,15
  (Note 2) As the clutch does not work at drill position, do not fasten the small screws.
  3) Working with charged battery --- Same as 6072D and 6012D.(The below table is only for reference.)
           Size (mm) Material Number of                   Drill      Material Plate           Number
                                  screwing                dia.(mm)                thickne        of
                                                                                  ss(mm) drilling
             3.5x20               500 pieces                   3     Cold                        200
                                  400 pieces                         rolling         1.6
Woode
             4.5x20   Lauan                                  6.5     steel                        40
n screw                                           Steel              plate
            *5.1x35               90 pieces                    3     Aluminu                     650
                                                                                     1.6
(Note 3) The values marked by * in the table                  10     m plate                     110
are the one for low speed and others are the                   9                                 300
ones for high speed.                              Wood               Lauan           25
                                                             *15                                  90
