Image preview - the first page of the document
60958-WW-1


>> Download 60958-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                    Modifications of Flat Washer 37 and Tool Holder
                                                                                                                60958
                                                                                                                60977
For Models                 HM1202, HM1202C, HM1242C

Country                    All countries
Description                For further improvement in hammering action;
                           1) Flat Washer 37 has been made thicker and harder.
                           2) The groove on Tool Holder that holds Ring Spring 34 has been made deeper.


                                        Tool Holder

Flat Washer 37
                                        Ring Spring 34       1) Flat Washer 37 (Part No.267197-0)

Barrel
                                                                      Current                             New
                                                                    [Cross section]

                                                                                      2.0mm                        2.2mm

                Crank Housing side


2) Tool Holder (Part No.323878-7 for HM1202 & HM1202C, 323961-0 for HM1242C)
                           Current                                                            New
                      [Cross section]
                                           Tool Holder                                   Tool Holder
    Flat Washer 37

    Barrel                                 Ring Spring 34                                Ring Spring 34




                                                                                         The groove for Ring Spring 34
