Image preview - the first page of the document
6095D-TE


>> Download 6095D-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
         Models No.              6095D
                                                                                                                New Tool


         Description             Cordless Driver Drill

CONCEPT AND MAIN APPLICATIONS                                                                 58mm(2-9/32")

Model 6095DQ is basically the same as the existing
Model 6095DW except the following.




                                                                                                                 262mm(10-5/16")
                  Fast Charger      Carrying Case
     6095DQ         DC9015             Plastic
     6095DW         DC9100              Steel

Fast Charger DC9015 charges Makita battery
cartridges(7000,9000 and 9100) in ONLY 15 MINUTES.


                                                                                    270mm(10-5/8")
    Specifications
     DC Magnet Motor 9.6V
     Capacities     Steel               10mm (3/8")
                    Wood                18mm (11/16")
                    Wood Screws         5.5mm (7/32") x 55mm (2-1/8")
                    Machine Screws 6mm (15/64")
     No Load Speed High                 0 - 1,100 R/min
                    Low                 0 - 400 R/min.
     Net weight     4.0kg (8.8lbs) including Fast Charger DC9015, Battery Cartridge and Plastic Carrying Case


    Standard equipment
     Fast Charger DC9015, Battery Cartridge 9000, Phillips Bit 2-45, Plastic Carrying Case

    Optional accessories
     Various size of Phillips Bits, Various size of Slotted Bits, Various size of Socket Bits, Various size of Drill Bits,
     Rubber Pad Assembly, Foam Polishing Pad, Wool Bonnet, 12 V Fast Charger DC9012 ( Automotive Charger),
     Battery Cartridge 9000

    Features and benefits
      1.Fast Charger DC9015 charges Makita battery cartridges (7000, 9000, 9100) in ONLY 15 MINUTES.
      2.Convenient plastic carrying case in which extra battery cartridge and bit up to 150 mm (5-7/8") long can be stored
      3.No chuck key to lose
      4.Keyless chuck for greater ease in bit installation/removal
      5.6 Hi, 6 Low torque settings to match fastening and material
      6.Electric brake stops chuck quickly
      7.Overload protector safeguards against motor burnout
      8.Two variable speeds (Hi-Low) allow easy centering, fastening of long screws, temporary settings




     The standard equipment for the tools shown may differ form country to country
