Image preview - the first page of the document
6092D-TE


>> Download 6092D-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.              6092D, 6092DW
                                                                                                                     New Tool


     Description             MAKITA Cordless driver drill
CONCEPTION AND MAIN APPLICATIONS                                                                58mm
 This machine is the Cordless driver drill equipped
 with the non-step variable speed switch and the
 brake, which is driven through the battery 9000
 as the power source.




                                                                                                            262mm
 The 2-speed switching function by the gear
 allows the screw fastening and boring work for wide range.
 The 6092D consists of :
    6092D(MAKITA battery driver drill) ;
    DC9000(MAKITA fast charger) ;
    and battery 9000.                                                                           mm
                                                                                          247
 The 6092D is the model without battery and charger.
  Specifications
   Voltage(V)        Current(A)        Frequency(Hz)       Consumed         Rated               Max.
                                                           power(W)         output(W)           output(W)
         9.6                 -                  -               -                 -               -

   Motor                          DC 9.6 V Magnet motor
   No load speed                  0-1100/min. in high speed
                                  0-400/min. in low speed
   Chuck capacity                 1.5-10
   Boring capacity                10 mm for steel, 18 mm for wood
   Screwing capacity              Wooden screw5.5x55 mm
   Weight                         1.6 kg

  Standard equipment
  Chuck key S10 --- One piece
  + Bit 2-65 --- One piece
  Optional accessories
  Battery 9000, Drill 1.5, 2, 3, 4, 5, 6, Wooden drill 9, 12, 15, - bit 5-45, 5-82, 6-70, 6.35-45, 8-45, 8-70
  + Bit 1-65, 2-45, 2-65, 2-82, 2-110, 2-150, 2-250, 3-45, 3-65, 3-110,
  Rubber pad assembly, Wool bonnet 100, Buff 125, 12V fast charger DC9012(for charging through the cigarette
  lighter socket of car)

  Features and benefits
  (1) The 2-speed switching by the gear provides the excellent working efficiency for screwing and boring for wide
      range.
  (2) The non-step variable speed switch enables to position the wooden screw or the drill easily and the best rotation
      for the application can be selected.
  (3) The brake for instantaneously stopping the rotation allows to stop the operation at the desired position, thereby
      enabling easy screwing
  (4) The powerful maximum torque of about 120 kg-cm in low speed enables to bore easily the wood with 18 mm in
      diameter.
  (5) The overload protector(auto return type) is mounted for protecting the motor and switch from overload.
  (6) The relief corner just above the switch, for hanging the fingers, and the constricted root of the handle allows to
      hold the machine in well balance and to control the switch in well manner.
  (7) The battery is the cartridge system.
  (8) It is housed in the steel case.                                                                         Constricted
                                                                                                                    hatching

                                                                                    Relief corner



  The standard equipment for the tools shown may differ form country to country
Capacity
(1) Working volume per charging --- Same as 6012D.(However, see the reference values shown below for the large
    sized work which is over the specifications of 6012HD.)
(2) Working volume of max. boring and max. screw fastening capacities per charging

                        Material                           Size                           Working volume
  Boring                 Lauan     Drill dia.18 mm x Plate thickness 25 mm                    60 pieces
  Wooden screw           Lauan     Nominal dia.5.5 mm x Length 50 mm                          60 pieces
It should be used in low speed.
(3) Overload protection
     In the 6012HD, also for the max. adjusting torque, the clutch is activated to protect the overload. However, in
    the 6092D, if the overload happens, the overload protector(auto return type) will activate.
(4) Others --- Same as 6012HD.
Repair
There is no special cautions for repair.
