61129-WW-1


>> Download 61129-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION                                                                                     61129
                                                                                                          61398
                                                                                                          61399
                                                                                                         (Page 1 of 2)
Subject               Replacement of Fast Charger

For Models            4190D, 6017D, 6018D, 6019D, 6095D, 6096D, 6222D, 8402VD, DA301D, DA391D, UM104D

Country               Austria, France, Germany, Italy, Netherlands, Russia, Spain, Sweden, Switzerland, U.K.
                      Algeria, Reunion
Description           See below.

Fast Charger DC9701 has been replaced by Battery Charger DC9711. The features of the Battery Charger DC9711 are
as follows;
1) The charging time is always constant even if the input voltage (power source voltage) fluctuates.
2) The Battery Charger DC9711 can be stored in the current Plastic Carrying Case. See the illustration below for
   dimensions of the Battery Charger.
3) The Battery Charger DC9711 can charge High Capacity Batteries (2.6Ah/ 3.0Ah).


                          Current                                                      New
                  Fast Charger DC9701                                        Battery Charger DC9711


                             L                                                         L

                                                                       H
              H



              W
                                                                        W


                    Dimensions : mm ( " )                                       Dimensions : mm ( " )
               Width ( W )   80 (3-1/8)                                    Width ( W )   80 (3-1/8)
               Height ( H )  63 (2-1/2)                                    Height ( H )  63 (2-1/2)
               Length ( L ) 145 (5-3/4)                                    Length ( L ) 145 (5-3/4)




 Interchangeability(I/C)
 Item No.         Current part              Q'ty I/C              New part                     Q'ty        Note
            DC9701 Fast Charger               1     Yes DC9711 Battery Charger                        See note below.
                                                                                                1
            192762-5                                    193123-2
            DC9701 Fast Charger                         DC9711 Battery Charger                        For U.K.
                                              1     Yes                                         1
            192763-3                                    193124-0


 Note
For Austria, France, Germany, Italy, Netherlands, Russia, Spain, Sweden, Switzerland, Algeria, Reunion
                                                                    61129
                                                                    61398
                                                                    61399
                                                                  (Page 2 of 2)

Implementation
Machines manufactured in MJ (Makita Japan)
4190D : From serial No.517237E (Jan., 2001)
DA301D: From serial No.523305E (Sep., 2000)
DA391D: From serial No.871690E (Dec., 2000)
UM104D: From serial No.501694E (Nov., 2000)

Machines manufactured in MME (Makita Manufacturing Europe Ltd.)
6017D : From serial No. 182549G (Dec., 2000)
6018D : From serial No. 181312G (Nov., 2000)
6019D : From serial No. 311807G (Nov., 2000)
6095D : From serial No. 549017G (Nov., 2000)
6096D : From serial No. 170100G (Jan., 2001)
8402VD: From your order received by us in/after Apr, 2001
