Image preview - the first page of the document
61482-WW-1


>> Download 61482-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Armature
                                                                                                             61482


For Models            5014NB, 5016NB

Country               All countries

Description           Armature has been changed as illustrated below. The new Armature is the same as the current
                      part described in Technical Information No. 57733.


                       Current                                                           New

                                       Bearing                                                     Bearing

                                                                                                    Fan Bush

                                                     Fan                                                       Fan

                                      Fan Bush




Interchangeability(I/C)
Item No.       Current part              Q'ty I/C            New part                     Q'ty          Note
           Armature Assembly                          Armature Assembly
    76                                     1                                               1     100/115V
           514555-4                                   514795-4
           Armature Assembly                          Armature Assembly
    76                                     1                                               1     200V
           514558-8                                   514798-8
           Armature Assembly                          Armature Assembly
    76                                     1                                               1     220V
           514557-0                                   514797-0
           Armature Assembly                          Armature Assembly
    76                                     1                                               1     240V
           514559-6                                   514799-6


Note
Interchangeability mark ;      means that the new part is substituted for the current.

Implementation
5014NB: Discontinued since May, 1995
5016NB: Discontinued since May, 1995
