Image preview - the first page of the document
6172D-TE


>> Download 6172D-TE documenatation <<

Text preview - extract from the document
T ECHNICAL INFORMATION
     Models No.          6172D
                                                                                                    New Tool


     Description         MAKITA 10 mm (3/8") Cordless driver drill                          52mm(2-1/16")


CONCEPTION AND MAIN APPLICATIONS
 Model 6172d was developed to increase the maneuverability




                                                                                                               208mm(8-3/16")
  of the existing Models 6012D and 6072D.
 It has a keyless chuck for greater ease in bit
 installation/removal and well-designed handle which makes
  bit centering easier and operationmore convenient.
  Model 6172D is sold without a battery cartridge
 and a fast charger.Model 6172DW includes a
 battery cartridge 7000 and a fast charger DC9700.
                                                                                                 8")
                                                                                      258mm(10-1/
  Specifications
    Motor                    DC 7.2 V Magnet motor
    No load speed            0-600 R/min. in high speed
                             0-250 R/min. in low speed
    Chuck capacity           Steel 10mm(3/8")
                             Wood 15 mm (9/16")
    Wood screws              5.1mm(1-3/64")x35 mm(1-3/8")
    Net Weight               1.2 kg(2.6lbs)


  Standard    equipment
  +Phillips Bit 2-65 --- One piece

  Optional    accessories
  Battery Cartridge 7000, Various size of Drill 1Bit,Various size of Phillips Bits,Various size of Slotted Bits,
  Form Pollishing Pad 125, Wool bonnet 100, Rubber Pad Assemble,Various size of Abrasive Discs,
  fast charger DC9700,DC9015,DC7012.

  Features     and benefits
  (1) Keyless chuck for greater ease in bit installation/removal.
        No chuck key to loose.
  (2) Improved motor which does not require overload protector.
      This means that you can continue to work without interruption by overload protector.
  (3) Well-designed handle (gripping angle) makes bit centering easier and operation more convenient.
  (4) 2-speed gear selection with variable speed in eather range for a variety of driving or drilling applications.
  (5) Built in feedback circuit produces high power even at low speed.
  (6) Electric brake quickly stops chuck for perfect control when driving screws.
  (7) Reversing feature for screw/bit removal.




  The standard equipment for the tools shown may differ form country to country
Repair
There is no special cautions for repair.

Circuit diagram
