61994-WW-1


>> Download 61994-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject             Change of Hex. Socket Head Bolt
                                                                                                     61994


For Models          4322, 4322M, 4323, 4323M,4324
Country             All countries
Description         For standardization, Part No. of Hex. Socket Head Bolt M4x16 has been changed from 266178-1
                    to 922128-3. However, the Hex. Socket Head Bolt itself remains unchanged.

                                                      Base




                                                                          Retainer Complete




              Part No. of this Hex. Socket Head Bolt M4x16
              has been changed from 266178-1 to 922128-3.


Interchangeability(I/C)
Item No.         Current part                 Q'ty I/C          New part                      Q'ty     Note
See note Hex. Socket Head Bolt M4x16                   Hex. Socket Head Bolt M4x16
                                               1   Yes                                         1
below. 266178-1                                        922128-3


Note
 Model 4322 4322M 4323 4323M 4324
Item No. 017 017   017  017   046


Implementation
4322 : From serial No. 46603E (Sep., 2000)
4322M: From serial No. 1691E (Sep., 2000)
4323 : From serial No. 171122E (Sep., 2000)
4323M: From serial No. 6402E (Sep., 2000)
4324 : From serial No. 88803E (Sep., 2000)
