Text preview - extract from the document
TECHNICAL INFORMATION
Subject             Addition of O Ring 44
                                                                                                      61907

For Models          5603R, 5703R
Country             All countries
Description         O Ring 44 has been added on Bearing Box. Accordingly a groove to install the O Ring 44 has
                    been made in the Bearing Box as illustrated below.

                                                        New




                                Groove to install
                                O Ring 44                 O Ring 44
                                                          (213560-5)




                 Cross Section of
              Bearing Box (317469-4)

Interchangeability(I/C)

 Item No.        Current part                Q'ty I/C      New part              Q'ty            Note
5603R : 006 Bearing Box                       1   No Bearing Box                  1
5703R : 009 316884-9                                 317469-4                           Interchangeable as a set
                                                     O Ring 44                    1
    077
                                                     213560-5

Implementation
5603R : From serial No.67377G (Jan.,2001)
5703R : From serial No.191175G (Jan.,2001)
