Image preview - the first page of the document



>> Download 6203D-TE documenatation <<

Text preview - extract from the document

T       ECHNICAL INFORMATION
         Models No.                6203D
                                                                                                          New Tool


         Description               Cordless driver drill

CONCEPTION AND MAIN APPLICATIONS                                                             233 mm

These are the competitive models against main competition products. Three types
of 10mm cordless driver drill are 9.6V, 12V and 14.4V applications.
Their benefits are:
Comfortable handle shape, light-weight and well balanced body.
Durable motor that carbon replacement is possible without disassembling the                                      241 mm
machine.
New variable-speed switch has a large stroke in variable speed range, that makes
speed control easy.
Changeover of rotation direction can be selected by one hand thanks to the
convenient one-touch push-button switch.
Large capacity battery (2.0Ah) can be replaced easily by push-button mechanism
                                                                                                  77 mm
                                233 mm                                         233 mm                            6203DA




                                                      241 mm                                   246 mm




                                                     6213DA                                      6233DA
                                   94 mm
     Specifications                                                                94 mm


     Model                           6203DWAE                   6213DWAE             6203DWA 6203DWAE
     Voltage                         DC 9.6V                     DC 12V                    DC 14.4V
     Current                                                      2.0 Ah
     Battery (Ni-cd battery)       9122x2units                 9122x2units          1422x1unit 1422x2units
     Fast charger                                                DC1410
     No load High                  0-1200 min.                 0-1400 min.                0-1300 min.
     speed    Low                   0-400 min.                  0-450 min.                 0-400 min.
     Chucking ability                                    1.0 (1/32") - 10 (3/8")
     Drilling Iron material                                   10mm (3/8")
     capacity Wood material                                   25.4mm (1")
     Torque adjustment                                      17-step + direct
     Max.tightening torque     230kgf
