Image preview - the first page of the document
>> Download 6214D-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. 6214D
New Tool
Description Cordless Driver Drills
<6214D> 197mm(7 3/4")
CONCEPTION AND MAIN APPLICATIONS
Model 6214D is 12V l0mm cordless driver drill, which is
efficient for driving approx.40mm wood screw and drilling
approx.9mm hole in wood. Its brief benefits are ;
235mm
(9 1/4")
*Compact design
*Light weight
*Equipped with electric brake
*Longer life motor by replacing carbon brushes
Model 6314D is l3mm version of model 6214D.
Model Battery Fast Charger Plastic Carrying Case
6214/6314DA 1222(Ni-Cd) No No 94mm
/16")
6214/6314DWA 1222(Ni-Cd) DC1411 Yes (3 11
6214/6314DWAE 1222(Ni-Cd)X2 DC1411 Yes
6214/6314DWBE 1222(Ni-MH)X2 DC1411 Yes <6314D>
208mm(8 3/16")
Specifications
Motor DC 12V magnet,motor
Battery Battery 1222 Ni-Cd,12V,2.0Ah)
235mm
(9 1/4")
Battery 1223 Ni-MH,12V,2.2Ah)
No load speed High:0-1100rpm Low:0-350rpm
Chuck capacity 6214D 0.8mm(1/32")-10mm(3/8")
6314D 1.5mm(1/16")-13mm(1/2")
Max.drilling 6214D Steel 10mm(3/8")
capacities Wood 24mm(15/16")
6314D Steel 13mm(1/2")
Wood 24mm(15/16")
Max.driving Wood screw 6.4mm(1/4")x55mm(2-3/16") 94mm ")
16
capacities Machine screw,Nut 6mm(1/4") (3 11/
Setting of fastening torque 16 stages+drill-mode
Declutching torque 0.5-5N-m (0.4-3.6ft-lbs)
(5-50Kgf-cm)
Max.fastening High Speed 7N-m(5.1ft-lbs)(70Kgf"cm)
torque(drill-mode) Low 21N-m(15.2ft-lbs)(210Kgf-cm)
speed
Net weight 1.7Kg(3.2lbs)
Standard equipment
Philips Bit 2-65 ----------------- 1 pc.
Battery Cover ------------------- 1 pc.
Set Plate --------------------------1 pc.
Plastic Carrying Case ----------1 pc. (except Model 6214/6314DA)
The standard equipment may differ country to country.
Optional accessories
Drill Bit 1.5,2,3,4,5,6 Drill Bit for wood 9,12,15
Philips Bit 1-65,2-45,2-65,2-110,2-150,2-250,3-45,3-65,3-110
Slotted Bit 5-45,5-82,6-70,6.35-45, 8-45,8-70
Socket Bit 7-55,8-55,10-55
Foam Polishing Pad 125 Rubber Pad Assembly Wool Bonnet 100
Battery 1200, 1202, 1202A, 1220, 1222,1233
Fast Charger DC1411,DC1209 (European countries only)
Fast Automotive Charger DC1412 Holster
Features and benefits
See the attached sheet for more information.
The standard equipment for the tools shown may differ from country to country.
<#6214D> Highest driving capacity
among same class tools
Length:197mm
(at driving 4.1x38 screw)
40mm shorter than Model 6211D
Makita 6211D/6311D 237mm 110% of Makita 6211D/6311D
6213D 233mm
Longer life motor
by replacing carbon brushes
10mm keyless drill chuck
Push button for reversing
16 stages of clutch + drill-mode direction of rotasion
Fastening torque can be set
every 0.3N.Em(3Kgf.Ecm) from
0.5N.Em (5Kgf.Ecm) to 5N.Em (5Kgf.Ecm).
Variable speed control switch High capacity battery 1222(2.0Ah)
easy to control speed
.can be removed easily by push button
.Battery without push buttons can be u
Light weight:1.7Kg
with set plate(standard equipment).
0.2Kg lighter than
Model 6211D/6311D Max.fastening torque:
21N-m(210Kgf-cm)
Length:209mm
38mm shorter than Model 6311D
<#6314D> 6311D:247mm
6313D:243mm
13mm keyless drill chuck.
Other features and benefits
are equal to #6214D.
Fastening torque by setting cance ring
Fastening torque
(ft-lbs)(kgf-cm)[N-m]
(15.9)(22.0)21.6
Low speed
(14.5)(200)19.6
(13.0)(180)17.6
(11.6)(160)15.7
(10.1)(140)13.7
( 8.7)(120)11.8
( 7.2)(100) 9.8
( 5.8)( 80) 7.8
High speed
(4.3)(60)5.9
(2.9)(40)3.9
(1.4)(20)2.0
( 0 ) ( 0 ) 0
1 2 4 6 8 10 12 14 16 Position of
Change Ring
M3 M4 M5 M6 Size of screw
16 stages of clutch
Proper festening torque for machine screw M3 - M6 can set.
Matching surface can be secured for various wood screws and woods.
Repair
(1) Cautions in assembling
To replace the gear assembly, first disconnect the drill chuck.(If the housing only is disassembled, its no need to
disconnect the chuck.) Use care not to miss the compression spring 4 inside the speed change lever since it can
be easily jumped out when disassembling.
(2) Cautions in assembling
(a) Assembling of the motor and gear assembly
*As the motor bracket is mounted on the gear speed change lever
assembly for repair, turn the motor bracket
counterclockwise(viewed from the motor bracket
side) to remove it from the gear assembly.
compression spring 4
1) Screw the motor bracket into the motor. Figure 1
2) Turn the motor assembling parts shown in1) in clockwise(viewed from the motor bracket side) to
assemble them on the gear assembly.
gear assembly
Motor
motor bracket
Turning direction in installation
Figure 2
(b) Assembling of the leaf spring
Assemble the leaf spring on the housing L as shown on the figure 3.
Leaf spring
Inner side of housing L
Figure 3
(c) Assembling of the speed change lever
1) Set the two pieces of compression spring 4 in the speed change lever.
2) Assemble the speed change lever assembly on the protrusion of the change lever as shown on the figure 4
while using care that the compression spring 4 may not jump over.
Gear assembly Speed change lever assembly
Speed change lever Protrusion on the change lever
Gear assembly
Compression spring 4
Figure 4
(d) Assembling on the housing
1) To assemble the one body of gear assembly and motor etc. on the housing L, place the speed change lever
on the position shown on the figure 5.
Inner side of housing L
The speed change lever should
be positioned at either side. m
Figure 5
(e) Assembling of the chuck
1) Place the chuck on the spindle face.
2) Mount the hexagon rod spanner on the chuck and use the vice to fix them.
3) Set to the drill mode, normal turning and low speed.
4) Set the full charged battery and securely hold the handle.*1
5) Allow the trigger to full speed in about 1 second while no impact is adding.
*Insufficiently holding the handle may cause the handle to turn around in locking. This machine is going
to turn clockwise.
6) Widen the claw of chuck at maximum and then fasten the screw for holding the chuck.
*The left-handed screw is used.
Circuit drawing
M1 Red
T+
Spring terminal Switch DC motor
T-
M2 Black
