Image preview - the first page of the document
6216D-TE


>> Download 6216D-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
       Models No.               6236D/6216D
                                                                                                                                   New Tool


       Description             Cordless Driver Drill
                                                                                                                          9/16")
CONCEPTION AND MAIN APPLICATIONS                                                                                    243(9-
  Model 6236D and 6216D are 10mm version of existing Model
  6336D and 6316D.




                                                                                             6216D 240mm(9-7/16")
                                                                         6236D 244(9-5/8")
    Model                Battery            Charger
   6236DWAE       Battery 1422 x 2 pcs
   6236DWBE       Battery 1433x 2 pcs
                                             DC1411
   6216DWAE       Battery 1222 x 2 pcs
   6216DWBE       Battery 1233x 2 pcs

                                                                                                                                        94 6")
                                                                                                                                             /1
                                                                                                                                          11
                                                                                                                                      (3-




  Specifications
                                           6236D                               6216D
    Motor                                        Direct current magnet motor
    Battery                 Battery 1422 NiCad 14.4V, 2.0Ah Battery 1222 NiCad 12V, 2.0Ah
                            Battery 1433 NiMH 14.4V, 2.2Ah Battery 1233 NiMH 12V, 2.2Ah
    Speed at no load                             High speed 0~1300 R/min
                                                    Low speed 0~400 R/min
    Chuck capacity                                   1.5(1/16") - 13(1/2")
    Drilling capacity                                Iron works 10mm(3/8")
                              Wood works 36mm(1-7/16")             Wood works 30mm(1-3/16")
    Torque adjusting                           16 levels + Direct connection
    Max. tighten torque      38 N.m(390 kgf-cm,28ft
