Image preview - the first page of the document
6222D-TE


>> Download 6222D-TE documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION

                                                                                             ")
                                                                                                   New Tool

          For Models           6222D                                                 202(8
          Description          Cordless Driver Drill



CONCEPTION AND MAIN APPLICATIONS
9.6 V Driver drill based on 6221D, by changing the battery to New
push button system one. Like 6221D, there is no gear change, but
                                                                       221(8-3/4")
good operativity because of best setting of rotation and torque.
     Model           Battery          Charger         Plastic case
  6222D             9120...1pc            No              No
   6222DWE          9120...2pc         DC9700             Yes
Model 6222D will not be produced for the time being.                                                     ")
                                                                                                  77(3
Besides, these models are only for export and manufactured by MCC.


   Specifications
       Motor                                   Direct current magnet motor HC683LG-63728
       Battery                                 NiCad Battery 9120(9.6V 1.3Ah)
       Current                                 Direct current 9.6 V
       Speed at no load                        0~700 R/min
       Chuck capacity                          0.8~10mm
                              Iron works       10mm
       Drilling capacity
                              Wood works       18mm
       Screwing capacity                       Wood screw 5.1x35 mm
                                               Machine screw and Nut 6 mm
       Max. tighten torque                     approx. 80kgf
