62308-WW-1


>> Download 62308-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject                 Change of Fan 54
                                                                                                                62308


For Models              4304, 4304T, 4305, 4305T
                        This modification applies to the machines manufactured in MME only.
Country                 European countries, Algeria, Bhutan, Reunion, U.S.A., Canada, Mexico, Panama, Argentina,
                        Australia, New Zealand

Description             To enhance the durability of Fan 54 for the subject models, its material has been changed as shown
                        below. There is no change in the shape between the current one and the new one.

                        The part number of Armature assembly which includes this fan remains unchanged.

                          Current                                                                  New
               Material : PA6 (Polyamide only)                 Material : PA6-GF30 (Mixture of Polyamide and Glass fiber)


Interchangeability(I/C)

    Item No.         Current part              Q'ty   I/C           New part                  Q'ty       Note
4304 : 037  Fan 54                               1          Fan 54                             1
4304T : 064 241875-0                                        240039-3
4305 : 023
4305T : 050


Note
Interchangeability mark ;           means that the new part is substituted for the current.

Implementation
4304 : From serial No.171330G (Sep., 2000)
4304T : From serial No.145731G (Sep., 2000)
4305 : From serial No.60606G (Sep., 2000)
4305T : From serial No.120435G (Sep., 2000)
