Image preview - the first page of the document
62658-WW-1


>> Download 62658-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Cap 31
                                                                                                        62658

For Models            BHR200, HK0500, HR160D, HR2010, HR2400, HR2410, HR2412, HR2413,HR2420, HR2430,
                      HR2431
Country               All countries
Description           Cap 31 has been modified as shown below.

                       Current                                                        New
                                    Bit                    3.5 mm                               Bit
         Cap 31                                                         Cap 31
       (286248-0)                                                     (286265-0)




                     Tool Holder                                                 Tool Holder


                    Chuck Cover                                                 Chuck Cover

Interchangeability(I/C)

Item No.    Current part             Q'ty I/C        New part                  Q'ty               Note
  See    Cap 31                                 Cap 31                             The current Cap 31 can be used
                                       1                                         1
 below 286248-0                                 286265-0                           as a replacement part for HK0500.

BHR200, HK0500, HR2010, HR2410, HR2412, HR2413, HR2420, HR2430, HR2431: 001
HR160D: 067
HR2400: 080

Note
Interchangeability mark ;    means the new part can be substituted for the current.

Implementation
Machine manufactured in MJ (Makita Japan)
BHR200: From serial No.7765E (Nov.,2000)
HK0500: From serial No.19157E (Nov.,2000)
HR160D: From serial No.519276E(Nov.,2000)
HR2010: From serial No.114706E(Nov.,2000)
HR2400: From serial No.308932E(Nov.,2000)
HR2410: From serial No.468071E(Nov.,2000)
HR2412: To be informed later
HR2413: From serial No.12083E(Feb.,2001)
HR2420: From serial No.28849E(Nov.,2000)
HR2430: From serial No.3681E(Nov.,2000)
HR2431: From serial No.1501E(Dec.,2000)
Machine manufactured in MCC (Makita (China) Co., Ltd.)
HR2010: From serial No.13509K(Mar.,2001)
HR2410: From serial No.47697K(Mar.,2001)
HR2412: To be informed later
HR2413: From serial No.289K(Mar.,2001)
