Image preview - the first page of the document
62690-WW-1


>> Download 62690-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Switch
                                                                                                             62690
                                                                                                            Page 1 of 2

                       HP1200, HP1500, HP1501, HP2030, HP2031, HP2032, HP2033, HP2040, HP2041, HR2410,
For Models             HR2412, HR2413, HR2420, HR2430, HR2431, 6307, 6407, 6408, 6410, 6807, 6821
Country                All countries
Description            See below.

Applicable Switches:
Manufacturer      Cat. No.                Rating
                J1MK711W        8A 125V AC, 8(8)A 125V
                J2MK711X        6(6)A 250V
    EATON       J2MK711M        6(6)A 250V
                J0MK711         8A 125V AC, 6(6)A 250V
                J1MK721DV       8A 125V AC, 6(6)A 250V

1. O Ring on Trigger Shaft and Compression Spring inside Switch have been replaced. See figure 1 below.

                                                                    Compression Spring




                                             O Ring

                                                                                        (Fig. 1)

2. To distinguish the New Switch from the current one, a silver dot is printed on each of the side and the back of the New
   Switch as shown in figure 2 below.




                                             Silver Dots
                                                                                        (Fig. 2)
3. If you have Switches with lot No. 0001 - 0034 in your stock, send them back to Makita Japan. Switches with lot No.
   0035 and over can be used as a replacement part. See figure 3 below.




                                                         Read the lot No. as follows:


                    Marking
                     8(8)A 125V       5E4                  Manufacturing Year Manufacturing Week
                     J1MK721DV            Lot No.


                                       0001 - 0034

                                                                                               (Fig. 3)
                                                                                                              62690
                                                                                                             Page 2 of 2
 Interchangeability(I/C)
Item No.      Current part             Q'ty I/C            New part                       Q'ty          Note
See note Switch                          1
                                                    Switch                                 1
below. 651972-8                                     651972-8                                     For HR2410, HR2420,
See note Switch                          1
                                                    Switch                                 1     HR2430, HR2431
below. 651973-6                                     651973-6
See note Switch                          1
                                                    Switch
                                                                                           1     For HR2413
below. 651974-4                                     651974-4
See note Switch                                     Switch
                                         1                                                 1     For HR2412
below. 651977-8                                     651977-8
See note Switch                                     Switch                                       For HP1200, HP1500,
                                         1                                                 1
below. 651987-5                                     651987-5                                     HP1501, HP2030,
                                                                                                 HP2031, HP2032,
                                                                                                 HP2033, HP2040,
                                                                                                 HP2041,6307, 6407,
                                                                                                 6408, 6410, 6807, 6821

Note
1. Interchangeability mark ;    means that the new part is substituted for the current.
2. Item No. for Switch
     Model HP1200 HP1500 HP1501 HP2030 HP2031 HP2032 HP2033 HP2040 HP2041 HR2410 HR2412
   Item No.  6      6      6      53     53     54    54     42      42     73     78
     Model HR2413 HR2420 HR2430 HR2431             6307      6407     6408       6410      6807       6821
   Item No.  80     75    112    112                4         4         4         4         51         26

Implementation
Machines manufactured in MJ (Makita Japan)
HP1200: Discontinued since Feb., 2000
HP2030: From serial No. 44696E (Nov., 2000)
HP2032: From serial No. 8870E (Sep., 2000)
HP2033: From serial No. 10411E (Dec., 2000)
HP2040: From serial No. 101473E (Nov., 2000)
HP2041: From serial No. 46991E (Nov., 2000)
HR2410: From serial No. 468071E (Nov., 2000)
HR2412: From your order received by us in/after May, 2001
HR2413: From serial No. 11861E (Nov., 2000)
HR2420: From serial No. 28117E (Nov., 2000)
HR2430: From serial No. 3681E (Nov., 2000)
HR2431: From serial No. 1501E (Dec., 2000)
6307 : From serial No. 4421E (Aug., 2000)
6407 : From serial No. 3466E (Nov., 2000)
6408 : From serial No. 80671E (Nov., 2000)
6807 : From serial No. 7735E (Dec., 2000)
6821 : From serial No. 202140E (Nov., 2000)
Machines manufactured in MBR (Makita do Brazil)
To be informed later
Machines manufactured in MCA (Makita Corporation of America)
To be informed later
Machines manufactured in MCC (Makita China Co., Ltd.)
HP1500: From serial No.5001K (Apr.,2001)
HR2410, HR2412: To be informed later
HR2413: From initial production
6410 : From serial No.454934K (Dec.,2000)
Machines manufactured in MME (Makita Manufacturing Europe Ltd.)
This information does not apply to machines*
manufactured in MME because the switches on
the subject have not been used for them.
*HP1500, HP1501, HP2030, HP2031, HP2032, HP2033, HP2040, HP2041
