62613-WW-1


>> Download 62613-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Internal Gear Case
                                                                                                             62613


For Models            6990D, 6991D, 6992D

Country               All countries

Description           The following change has been implemented.

                       Current                                                         New
                   Internal Gear 51



                                  Internal Gear Case                                              Internal Gear Case




Internal Gear 51 and Internal Gear Case are individual       Internal Gear 51 and Internal Gear Case are integrated into
parts. Internal Gear 51 is made of steel and Internal Gear   one-piece unit. It is made of resin.
Case is made of resin.



Interchangeability(I/C)
Item No.       Current part                Q'ty I/C           New part                     Q'ty           Note
         Internal Gear Case                          Internal Gear Case                      1
  034                                        1    No
         417269-3                                    417268-5                                         Interchangeable
See note Internal Gear 51                                                                                  as a set
                                             1
below. 227001-5


Note
Item No. of Internal Gear 51
  Model 6990D 6991D 6992D
Item No. 044   044   045


Implementation
6990D: From serial No. 2357E (Dec., 2000)
6991D: From serial No. 1151E (Dec., 2000)
6992D: From serial No. 1587E (Dec., 2000)
