62804-WW-1


>> Download 62804-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Pad 150
                                                                                                               62804

For Models            BO6030, BO6040
Country               All countries
Description          To enhance the durability of Pad 150, the density of urethane sponge has been increased.
                     A line has been added on the hub of the new Pad 150 to distinguish the new Pad 150 from
                     the current one as illustrated below.

                                                           Current
                  Hub




                                   Urethane sponge



                                                              New
                  Hub

                   or


            Line is added here.


                                Urethane sponge
                            (with increased density)


Interchangeability(I/C)
All countries except for Canada, Guam, U.S.A., Panama
   Item No.       Current part        Q'ty I/C       New part                        Q'ty                Note
BO6030 : 046    Pad 150                           Pad 150 (Soft)                       1    Use the current pad 150 in your
                                        1
BO6040 : 033 743063-0                             193299-5                                  stock as a replacement part for
BO6030 : F12 Pad 150 (Soft)                       Pad 150 (Soft)                            BO6040. Do not use it for
                                        1                                              1
BO6040 : F03 794605-3                             193299-5                                  BO6030.
Canada, Guam, U.S.A., Panama
  Item No.     Current part                 Q'ty   I/C      New part                 Q'ty               Note
BO6030 : 046 Pad 150                                     Pad 150 (Soft)                1    Use the current pad 150 in your
                                              1
BO6040 : 033 743063-0                                    193286-4                           stock as a replacement part for
                                                                                            BO6040. Do not use it for
                                                                                            BO6030.

Note
Interchangeability mark ;         means that the new part is substituted for the current.

Implementation
BO6030 : From initial order
BO6040 : From serial No.6410E (Jan., 2001)
