Image preview - the first page of the document
62824-WW-1


>> Download 62824-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of D-Shaped Side Handle Assembly
                                                                                                                  62824


For Models            HM1100C, HM1140C
Country               European countries, Algeria, Reunion
Description           D-shaped side handle has been modified as illustrated below.

                    Current                                                              New
 Side Handle Assembly (134793-8)                           Side Handle Assembly (134909-5)
 (includes 6 components illustrated below.)                (includes 6 components illustrated below.)
                   Hex.Bolt M8x150
                   (265439-6)                               5
 3                            2                                                 6

                                  1                                                  4


                                  1. Handle Spring 60                                    4. Side Handle Base 60 Complete
                                     (344559-0)                                             (152620-7)
                                  2. Handle Base 60                             6        5. Side Handle
                          2          (416396-3) [2 pcs.]                                    (417003-1)
                                  3. Side Handle                                         6. Side Handle Cam
     Wing Nut M8                                                                           (417002-3) [2 pcs.]
                                     (416009-6)
     (252640-2)

 1. Handle Spring 60                       2               4. Side Handle Base 60 Complete
    (344559-0)                                 1              (152620-7)
                                                                                               4
 2. Handle Base 60
    (416396-3) [2 pcs.]
                                       2
 3. Side Handle                                            5. Side Handle
                          3                                                      5
    (416009-6)                                                (417003-1)                           6
                                                           6. Side Handle Cam
                                                             (417002-3) [2 pcs.]                     The new Side Handle
                                                                                                     and Side Handle Cam
                                                                                                     have already been used
                                                                                                   6 for HM1202 and
                                                                                                     HM1202C.

Interchangeability(I/C)
     Item No.             Current part                     Q'ty I/C     New part                       Q'ty       Note
                      Handle Spring 60                             Side Handle Base 60
HM1100C: 071                                                1   No                                      1
                      344559-0                                     Complete
HM1140C: 018                                                                                                  Interchangeable
                                                                   152620-7
HM1100C: 070, 072 Handle Base 60                                                                                   as a set
                                                            2   No
HM1140C: 017, 019 416396-3
HM1100C: 074      Side Handle                                         Side Handle
                                                            1   No                                      1
HM1140C: 015      416009-6                                            417003-1                                Interchangeable
HM1100C: 070, 072                                                     Side Handle Cam                              as a set
                                                                                                        2
HM1140C: 017, 019                                                     417002-3
HM1100C: B01      Side Handle Assembly                                Side Handle Assembly
                                                            1                                           1
HM1140C: B01      134793-8                                            134909-5
Interchangeability mark ;
 The arrow      means that the new part is substituted for the current.

Implementation
HM1100C: From serial No.34510E (Nov., 2000)
HM1140C: From serial No.2768E (The implementation month will be informed later.)
