62995A-WW-1


>> Download 62995A-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Switch
                                                                                                               62995A

                      6823, 6823TP, 6824, 6824TP, 6825, 6825TP, 6826, 6827, 6951, DP3002, DP3003, DP4000,
For Models            DP4001, DP4002, DP4003, JS1300
Country               All countries
Description           See below.
Some constituent parts of switch have been modified in order to improve the switch in durability.
The color of Trigger Shaft has been changed from black to white to distinguish the new switch from the current switch
as illustrated below. However the part number and the wiring remain unchanged.

                                                 Trigger Shaft (Color: Black          White)




Interchangeability(I/C)
 Item No.       Current part                Q'ty I/C            New part                   Q'ty            Note
           Switch                                        Switch
   006                                       1                                               1      For 6951
           651965-5                                      651965-5
See note 1 Switch                            1
                                                         Switch
                                                                                                    See note 2 below.
                                                                                             1
below.     651978-6                                      651978-6
See note 1 Switch                            1
                                                         Switch
                                                                                             1      See note 3 below.
below.     651991-4                                      651991-4
           Switch                                        Switch
   041                                       1                                               1      For JS1300
           651296-2                                      651296-2

Note
1. Item No. for Switch
    6823 6823TP 6824 6824TP 6825 6825TP 6826 6827 DP3002 DP3003 DP4000 DP4001 DP4002 DP4003
    041    041   038  038   038    038   041 041    043   043    039    039    039    039
2. For 6823, 6823TP, 6824, 6824TP, 6825, 6825TP, 6826, 6827
3. For DP3002, DP3003, DP4000, DP4001, DP4002, DP4003
4. Interchangeability mark ;    means that the new part is substituted for the current.

Implementation
Machines manufactured in Japan                              Machines manufactured in China
6823 : From serial No. 17133E (Mar., 2001)                  6823, 6823TP, 6824, 6824TP, 6825, 6825TP, 6826, 6827 :
6823TP: From your order received by us in/after Apr., 2001 To be informed later
6824 : From serial No. 45554E (Mar., 2001)
6824TP: From your order received by us in/after Apr., 2001
6825 : From serial No. 121668E (Mar., 2001)
6825TP: From your order received by us in/after Apr., 2001
6826 : From serial No. 2779E (Mar., 2001)
6827 : From your order received by us in/after Apr., 2001
6951 : From serial No. 7712E (Feb., 2001)
DP3002: From serial No. 1648E (Feb., 2001)
DP3003: From serial No. 1954E (Dec., 2000)
DP4000: From your order received by us in/after Apr., 2001
DP4001: From serial No. 2530E (Dec., 2000)
DP4002: From serial No. 3841E (Jan., 2001)
DP4003: From serial No. 2775E (Dec., 2000)
JS1300 : From your order received by us in/after Apr., 2001
