Image preview - the first page of the document
62935-WW-1


>> Download 62935-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Addition of Seal Ring and Change of Gear Housing Cover Complete, etc.
                                                                                                          62935
                                                                                                         (Page 1 of 2)


For Models            6822

Country               All countries

Description           See below.



                                           Pin 8                  Thrust Needle Bearing 1023




                                   Gear Housing Cover Complete



1. Seal Ring has been added as illustrated below. Consequently, a groove for accepting the Seal Ring has been made on
   the Gear Housing Cover Complete.
                                                                            Groove




                                            Seal Ring
                                                                Gear Housing Cover Complete

2. Thrust Needle Bearing 1023 has been replaced by Thrust Needle Bearing 821. See the illustration below for difference
   between Thrust Needle Bearing 1023 and Thrust Needle Bearing 821.
                                       Thrust Needle Gauge 1023 (a constituent part of Thrust Needle Bearing)
                                       has been replaced by Thrust Needle Gauge 821.
       Washer 824 (a constituent part of
       Thrust Needle Bearing) remains
       unchanged.



                                        Washer 1023 (a constituent part of Thrust Needle Bearing)
                                        has been replaced by Washer 821.

3. Pin 8 has been changed as illustrated below.

                       Current                                                        New
                                                                                                         62935
                                                                                                        (Page 2 of 2)

4. Plane Bearing 6 (a constituent part of Gear Housing Cover Complete) has been replaced by Plane Bearing 8.

                          Current                                                   New
         Plane Bearing 6                                            Plane Bearing 8
                                                                                              Groove




 Interchangeability(I/C)
Item No.           Current part         Q'ty I/C            New part                   Q'ty            Note
   044                                              Seal Ring
                                                                                        1
                                                    421795-6
           Thrust Needle Bearing                    Thrust Needle Bearing
   018     1023                           1    No   821                                 1
           212951-7                                 212047-4                                     Interchangeable
           Pin 8                                    Pin 8                                             as a set
   015                                    1    No                                       1
           268034-1                                 256699-1
           Gear Housing Cover                       Gear Housing Cover
   019     Complete                       1    No   Complete                            1
           150997-4                                 152909-3


Implementation
From serial No. 54706E (Dec., 2000)
