TECHNICAL INFORMATION
Subject                Change of Arm Band and Suspender
                                                                                                               63003


For Models             4604D, 4604DW

Country                All countries
Description            The parts in subject have been changed so that each band of them increase in strength.




                         Arm Band




                                                                      Suspender

                                       Current                                                 New
                                                Gray                                                Black




 Arm Band


                                                                         Makita logos are smaller than the current ones.

                                        Gray                                                     Black



 Suspender

                                                        Makita logo                                      No Makita logo,
                                                                                                         Not elastic
                                        Elastic band


Interchangeability(I/C)

Item No.       Current part                    Q'ty I/C           New part                        Q'ty         Note
           Arm Band                                        Arm Band
  A04                                           1      Yes                                          1
           166054-8                                        166062-9
           Suspender                                         Suspender
  A06                                           1      Yes                                          1
           168335-6                                          168356-8

Implementation
From serial No.5402E (May,2001)
