Image preview - the first page of the document
63024-WW-1


>> Download 63024-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Ball Bearing 6002DDW
                                                                                                       63024

For Models           BO3700, BO5000, BO5001, BO6030, 3606, 3700, 3700B, 3701, 3702, 3702B, 3706, 4401,
                     5017RKB, 5103R, 5143R, 5603R, 5703R, 5705R, 5901B, 5902B, 5903, 5903R, 8406C, 9015A,
                     9046, 9741
Country              All countries
Description          For standardization, Part No. of Ball Bearing 6002DDW has been changed from 211227-9 to
                     211236-8. However, Ball Bearing 6002DDW itself remains unchanged.

Interchangeability(I/C)
Item No.      Current part               Q'ty I/C         New part                 Q'ty             Note
         Ball Bearing 6002DDW                                                              For all Models on the
                                           1    Yes Ball Bearing 6002DDW               1
See note 211227-9                                   211236-8                               subject except 9046
below.   Ball Bearing 6002DDW                       Ball Bearing 6002DDW
                                           2    Yes                                    2   For 9046
         211227-9                                   211236-8

Note
 Model     BO3700 BO5000 BO5001 BO6030 3606 3700 3700B 3701 3702 3702B 3706 4401 5017RKB
Item No.    018        015      015       032     014   015   020    015   016   015       014 021      010

 Model   5103R 5143R 5603R 5703R 5705R 5901B 5902B 5903 5903R 8406C 9015A  9046    9741
Item No. 060    070   007   010   010   006   006 042    047   006   040 066 & 069 008

Implementation
Machines manufactured in MJ (Makita Japan)                          Machines manufactured in MME
                                                                    (Makita Manufacturing Europe Ltd.)
BO5000: Discontinued since Apr.,1998
BO5001: From serial No.17533E (Jan., 2001)                          5017RKB : From serial No.1341G (Apr., 2001)
BO6030: From serial No.2812E (Jan., 2001)                           5603R : From serial No.68931G (Apr., 2001)
3606  : From serial No.64885E (Jan., 2001)                          5703R : From serial No.192939G (Apr., 2001)
3700  : Discontinued since Oct., 1991                               5705R : From serial No.8715G (Apr., 2001)
3700B : From serial No.402883E (Jan., 2001)                         5903R : From serial No.152121G (Apr., 2001)
3701  : From serial No.424107E (Feb., 2001)
3702  : From serial No.11817E (Feb., 2001)                          Machines manufactured in MBR
3702B : From serial No.15232E (Jan., 2001)                          (Makita do Brasil)
4401  : Discontinued since Oct., 1994
5103R : From serial No.21330E (Jan., 2001)                          3702B : To be informed later
5143R : From serial No.19875E (Jan., 2001)
5901B : From serial No.7156E (Feb., 2001)
5902B : From your order received by us in/after Apr., 2001
8406C : From serial No.11242E (Jan., 2001)
9015A : From your order received by us in/after Apr., 2001
9046  : From serial No.66642E (Jan., 2001)
9741  : From serial No.36032E (Jan., 2001)

Machines manufactured in MCA (Makita Corporation of America)
BO5000 : Discontinued since Apr.,1998
BO5001 : From serial No.209137A (Dec., 2000)
3606 : To be informed later
3706 : From initial production
Machines manufactured in MCC (Makita (China) Co., Ltd)
BO3700 : From serial No.69308K (May, 2001)
5903R : From initial production
