Image preview - the first page of the document

>> Download 6314D-TE documenatation <<

Text preview - extract from the document
    Models No.            6314D
                                                                                                          New Tool

    Description           Cordless Driver Drills
                                                                                   <6214D>        197mm(7 3/4")

  Model 6214D is 12V l0mm cordless driver drill, which is
  efficient for driving approx.40mm wood screw and drilling
  approx.9mm hole in wood. Its brief benefits are ;

                                                                                       (9 1/4")
  *Compact design
  *Light weight
  *Equipped with electric brake
  *Longer life motor by replacing carbon brushes
  Model 6314D is l3mm version of model 6214D.
  Model                 Battery         Fast Charger Plastic Carrying Case
  6214/6314DA         1222(Ni-Cd)            No                No                                     94mm
  6214/6314DWA        1222(Ni-Cd)         DC1411              Yes                                     (3 11
  6214/6314DWAE      1222(Ni-Cd)X2        DC1411              Yes
  6214/6314DWBE      1222(Ni-MH)X2        DC1411              Yes                   <6314D>
                                                                                                  208mm(8 3/16")

   Motor                               DC 12V magnet,motor
   Battery                             Battery 1222 Ni-Cd,12V,2.0Ah)

                                                                                       (9 1/4")
                                       Battery 1223 Ni-MH,12V,2.2Ah)
   No load speed                       High:0-1100rpm Low:0-350rpm
   Chuck capacity           6214D      0.8mm(1/32")-10mm(3/8")
                            6314D      1.5mm(1/16")-13mm(1/2")
   Max.drilling 6214D Steel            10mm(3/8")
   capacities               Wood       24mm(15/16")
                   6314D Steel         13mm(1/2")
                            Wood       24mm(15/16")
   Max.driving Wood screw              6.4mm(1/4")x55mm(2-3/16")                                      94mm ")
   capacities      Machine screw,Nut 6mm(1/4")                                                       (3 11/
   Setting of fastening torque         16 stages+drill-mode
   Declutching torque                  0.5-5N-m (0.4-3.6ft-lbs)
   Max.fastening            High Speed 7N-m(5.1ft-lbs)(70Kgf"cm)
   torque(drill-mode)       Low        21N-m(15.2ft-lbs)(210Kgf-cm)
   Net weight                          1.7Kg(3.2lbs)

  Standard equipment
  Philips Bit 2-65 ----------------- 1 pc.
  Battery Cover ------------------- 1 pc.
  Set Plate --------------------------1 pc.
  Plastic Carrying Case ----------1 pc. (except Model 6214/6314DA)
  The standard equipment may differ country to country.
  Optional accessories
  Drill Bit 1.5,2,3,4,5,6             Drill Bit for wood 9,12,15
  Philips Bit 1-65,2-45,2-65,2-110,2-150,2-250,3-45,3-65,3-110
  Slotted Bit 5-45,5-82,6-70,6.35-45, 8-45,8-70
  Socket Bit 7-55,8-55,10-55
  Foam Polishing Pad 125           Rubber Pad Assembly           Wool Bonnet 100
  Battery 1200, 1202, 1202A, 1220, 1222,1233
  Fast Charger DC1411,DC1209 (European countries only)
  Fast Automotive Charger DC1412                   Holster

  Features and benefits
  See the attached sheet for more information.

  The standard equipment for the tools shown may differ from country to country.
  <#6214D>                                                                Highest driving capacity
                                                                          among same class tools
                                                                          (at driving 4.1x38 screw)
                                          40mm shorter than Model 6211D
                                            Makita 6211D/6311 237mm 110% of Makita         6211D/6311D
                                                    6213D       233mm

                                                                        Longer life motor
                                                                        by replacing carbon brushes

 10mm keyless drill chuck
                                                                        Push button for reversing
16 stages of clutch + drill-mode                                        direction of rotasion

 Fastening torque can be set
 every 0.3N.Em(3Kgf.Ecm) from
 0.5N.Em (5Kgf.Ecm) to 5N.Em (5Kgf.Ecm).

                  Variable speed control switch                         High capacity battery 1222(2.0Ah)
                  easy to control speed
                                                                        .can be removed easily by push button
                                                                        .Battery without push buttons can be u
       Light weight:1.7Kg
                                                                         with set plate(standard equipment).
       0.2Kg lighter than
       Model 6211D/6311D                                                Max.fastening torque:

                                    38mm shorter than Model 6311D
          <#6314D>                    6311D:247mm

                 13mm keyless drill chuck.

                                                                     Other features and benefits
                                                                           are equal to #6214D.
Fastening torque by setting cance ring
Fastening torque


                                                                                    Low speed




( 8.7)(120)11.8

( 7.2)(100) 9.8

( 5.8)( 80) 7.8

                                                                                    High speed



( 0 ) ( 0 ) 0
                   1    2    4       6        8        10    12      14       16      Position of
                                                                                      Change Ring

                       M3   M4                    M5                  M6           Size of screw

     16 stages of clutch

         Proper festening torque for machine screw M3 - M6 can set.
         Matching surface can be secured for various wood screws and woods.
(1)     Cautions in assembling
        To replace the gear assembly, first disconnect the drill chuck.(If the housing only is disassembled, its no need to
        disconnect the chuck.) Use care not to miss the compression spring 4 inside the speed change lever since it can
        be easily jumped out when disassembling.

(2) Cautions in assembling
   (a) Assembling of the motor and gear assembly
       *As the motor bracket is mounted on the gear                         speed change lever
       assembly for repair, turn the motor bracket
       counterclockwise(viewed from the motor bracket
       side) to remove it from the gear assembly.
                                                                                compression spring 4

            1)   Screw the motor bracket into the motor.                                                       Figure 1

            2)   Turn the motor assembling parts shown in1) in clockwise(viewed from the motor bracket side) to
                 assemble them on the gear assembly.

                     gear assembly

                      motor bracket

                                                                           Turning direction in installation
                                               Figure 2

      (b) Assembling of the leaf spring
          Assemble the leaf spring on the housing L as shown on the figure 3.

                                                    Leaf spring

           Inner side of housing L
                                                              Figure 3
 (c) Assembling of the speed change lever
    1) Set the two pieces of compression spring 4 in the speed change lever.
    2) Assemble the speed change lever assembly on the protrusion of the change lever as shown on the figure 4
       while using care that the compression spring 4 may not jump over.

                              Gear assembly Speed change lever assembly

         Speed change lever                                                Protrusion on the change lever

                                                                                                    Gear assembly

            Compression spring 4

                                                             Figure 4

 (d)     Assembling on the housing
       1) To assemble the one body of gear assembly and motor etc. on the housing L, place the speed change lever
          on the position shown on the figure 5.

Inner side of housing L
                                                                                The speed change lever should
                                                                                be positioned at either side. m

                                                  Figure 5
  (e) Assembling of the chuck
    1) Place the chuck on the spindle face.
    2) Mount the hexagon rod spanner on the chuck and use the vice to fix them.
    3) Set to the drill mode, normal turning and low speed.
    4) Set the full charged battery and securely hold the handle.*1
    5) Allow the trigger to full speed in about 1 second while no impact is adding.
       *Insufficiently holding the handle may cause the handle to turn around in locking. This machine is going
        to turn clockwise.
    6) Widen the claw of chuck at maximum and then fasten the screw for holding the chuck.
       *The left-handed screw is used.

Circuit drawing

                                                   M1     Red

         Spring terminal                  Switch                                         DC motor

                                                   M2     Black
