Subject               Change of the color of Chuck Cover

For Models             HR3550C
Country               All countries

Description            The color of Chuck Cover has been changed from black to blue in order to distinguish SDS-Top
                       shank model HR3550C from SDS-Plus shank model HR3000C.

                                                   Chuck Cover


Item No.       Current part                  Q'ty I/C         New part                   Q'ty         Note
           Chuck Cover                                   Chuck Cover
  002                                         1                                           1
           417516-2                                      417705-9

Interchangeability marks :       means that the new part is substituted for current.

From serial No.1711E (Feb. 2001)
