Image preview - the first page of the document
6310-TE


>> Download 6310-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.            6310
                                                                                                             New Tool


     Description           2-Speed l3mm Drill

CONCEPTION AND MAIN APPLICATIONS                                                           307

  Designed to meet extra heavy duty job requirement for                                          68
  this class.




                                                                                                 178
  Specifications
                                                               Continuous Rating (W)
    Voltage (V)       Current (A)          Cycle (Hz)                                      Max. Output(W)
                                                              Input          Output
        110                5.3               50-60             500                                     400
        115                5.0               50-60             550                                     400
        200                2.9               50-60             550                                     400
        220                2.6               50-60             550                                     400
        230                2.5               50-60             550                                     400
        240                2.4               50-60             550                                     400

  NET WEIGHT                                                     2. Kgs.
  NO LOAD SPEED                             High                 0-2,000 RPM
                                            Low                  0-700 RPM
  CAPACITY          Drill chuck capacity                         2 -l3 mm
                    Drilling capacity       for steel            (Low : l3mm, High 8mm)
                                            for wood             (Low : 32mm, High 20mm)


  Standard equipment
   Chuck Key S-13 with a Holder
   Depth Rod assembly
   Grip (32)


  Features and benefits
  1. Extra heavy duty motor in light weight construction (2Kgs.)
  *Gives all round application from light to extra heavy duty work.
  2. 2 speed variable reversing switch
  *Makes this extra heavy duty drill operate much easier.
  3. Depth Rod with a plastic cap on the end
  *Allowes easier depth adjustment without scratiching materials




  The standard equipment for the tools shown may differ form country to country.
