Image preview - the first page of the document
63107-WW-1


>> Download 63107-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                1) Change of Inlet (for 4072D and 4073D only)
                                                                                                               63107

                       2) Change of installing method of Packing
For Models             4072D, 4073D, 4093D
Country                All countries
Description            To prevent dust in Dust Bag from falling out;
                       1) Brim has been added to Inlet as illustrated below. (for 4072D and 4073D only)
                       2) Packing has been installed upside down so that the upper part of valve will open as illustrated
                          below.

                            Current                                                       New


                                                                                                 Brim has been added.
                           Inlet                                                      Inlet
                        (416031-3)                                                 (417686-7)
                                   Housing                                                           Housing




        Packing                                                        Packing




      Under part of valve                                         Upper part of valve
      will open.                                                  will open.




                                        Dust Bag                                                    Dust Bag

Interchangeability(I/C)

   Item No.      Current part                   Q'ty I/C       New part                   Q'ty            Note
 4072DW : 023 Inlet                                        Inlet
                                                 1                                          1
 4073DW : 025 416031-3                                     417686-7

Note
Interchangeability mark ;       means that the new part is substituted for the current.

Implementation
To be informed later
