63132-WW-1


>> Download 63132-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                  Change of Ball Bearing
                                                                                                                63132


For Models               5017RKB

Country                  European countries, Algeria, Reunion

Description              For quick repairing, the Ball Bearing in the gear chamber of Blade Case Complete has been
                         changed from 608DDW (double sealed type) to 608 (seal-less type).
                         (It is difficult to put a double sealed ball bearing in the gear chamber when there is much grease
                         inside the gear chamber.)
                                                                      Blade Case Complete




                                 Ball Bearing

                           Helical Gear 41

                                 Spindle



                                                                        Gear Chamber

                                             Current                                                New
       Cat. No.                              608DDW                                               608
    of Ball Bearing                  (With seals on both sides)                         (No seals on either side)

       Part No.                              210005-4                                           211034-0


Interchangeability(I/C)
Item No.          Current part               Q'ty I/C             New part                   Q'ty           Note
           Ball Bearing 608DDW                         Ball Bearing 608
 015       210005-4                           1    Yes 211034-0                                1


Implementation
From Serial No. 1341G (Apr., 2001)
