Image preview - the first page of the document
6327D-TE


>> Download 6327D-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
   Models No.                 6327D, 6328D
                                                                                              L
                                                                                                              PRODUCT
                                                                                                                P1/7

   Description                Cordless Driver Drill 13mm (1/2")
CONCEPTION AND MAIN APPLICATIONS
     6327D : 12 V 13mm version of Mod.6227D
     6328D : 14.4 V 13mm version of Mod.6228D                              H

     The variation of these models are as follows.
                                Battery
      Model No.        No.     Type     V     Ah    Q'ty     Charger
      6327DW           1220    Ni-Cd 12       1.3   1 pc.    DC1470
      6327DWE          1220    Ni-Cd 12       1.3   2 pcs.   DC1470
      6327DWD          1234    Ni-MH 12       2.6   1 pc.    DC1411                           W
                                                                           Dimensions
      6327DWDE         1234    Ni-MH 12       2.6   2 pcs.   DC1411
      6328DW           1420    Ni-Cd 14.4     1.3   1 pc.    DC1470                 6327D      6328D
                                                                               L   220mm      220mm
      6328DWE          1420    Ni-Cd 14.4     1.3   2 pcs.   DC1470
                                                                                   8-5/8"     8-1/4"
      6328DWD          1434    Ni-MH 14.4     2.6   1 pc.    DC1411                235mm      240mm
      6328DWDE         1434    Ni-MH 14.4     2.6   2 pcs.   DC1411            H
                                                                                   9-1/4"     9-7/16"
                                                                                   94mm       94mm
                                                                               W
                                                                                   3-11/16"   3-11/16"
 Specification
       Model No.                                                       6327D                       6328D
       Voltage                                                         12 V                        14.4 V
       No load speed            High speed                                       0 - 1,100
       (min-1= rpm.)            Low speed                                         0 - 350
       Chuck ability                                                     1.5mm (1/16") - 13mm (1/2")
                                in Steel                                         13mm (1/12")
       Capacities
                                in Wood                                           24mm (15/16")
                                Screw                                           5.1mm x 63mm
                                                                                (3/16" x 2-1/2")
                                      High speed                              7Nm (71.4Kgf.cm / 62.0 in lbs)
      Max tightening torque                                                  22Nm (224.3Kgf.cm / 194.8 in lbs)
                                      Low speed
       Reversible action switch                                                        Yes
       Electric brake                                                                  Yes
       Torque adjustment                                                    16 stage and drill mode
       Net weight                                              1.6 Kg (3.5 lbs)                   1.7 Kg (3.7 lbs)

 Standard equipment
   * + - Bit 2-65 ................ 1 pc.
   * Battery cover ............ 1 pc.
   * Plastic carrying case... 1 pc.

   < Note > The standard equipment for the tool shown may differ from country to country.


 Optional      accessories
   Wool bonnet, Various drill bits for wood and metal, Various philips bits, slotted bits, socket bits,
   Rubber pad assembly, Buff 125
   Set plate for battery 1200, 1202, 1202A (Mod.6327D)
   Charger DC2101, DC1411, DC1422, DC1439, DC1470, DC1801
   Batteries
     for 6327D 1200, 1202, 1202A, 1222, 1233, 1234, 1235
    for 6328D 1420, 1422, 1433, 1434, 1435
Benefits    and features                                                                                      P2/7
  6327D, 6328D
           Torque adjustment                                 Mechanic 2 speed control
           in 16 stage + drill mode                          High speed mode providing speedy drilling in light duty.
           to match fastening and material                   Low speed mode providing high torque in heavy duty
                                                             and wide working area as shown in the diagram in the
                                                             next page.
  13mm Keyless drill chuck




             Variable speed control switch
             with brake for easy bit
             centering and fastening                                                              Reversible switch
                                                                                                  Easy to operate with one hand




                                                                                         Battery 12V - 14.4V




Comparison       of products

                                                 12 V                                    14.4 V
  Model No.
                                    6327D                 6227D              6328D                6228D
  No load speed High speed                                        0 - 1,100
  (min-1= rpm.) Low speed                                         0 - 350
  Max. tightening torque (Nm)                                 22 (194.8 in lbs)
  Capacity in steel : mm ( " )      13 ( 1/2 )            10 ( 3/8 )        13 ( 1/2 )        10 ( 3/8 )
  Equipped motor                                               Johnson
                                                               HC683LG

  Torque adjustment                      16 stage + drill                  16 stage + drill
  Overall length (mm)             220 (8-5/8")       210 (8-1/4")    220 (8-5/8")      210 (8-1/4")
  Weight (Kg)                    1.6 Kg (3.5 lbs) 1.5 Kg (3.3 lbs) 1.7 Kg (3.7 lbs) 1.6 Kg (3.5 lbs)
                                  + - Bit 2-65          + - Bit 2-65       + - Bit 2-65       + - Bit 2-65
  Standard equipment              Battery cover         Set plate          Battery cover      Battery cover
                                  Carrying case         Battery cover      Carrying case      Carrying case
                                                        Carrying case
 Comparison       of products
                                                                                                         P3/7
  Comparison of Mod.6226D with Model 6222D
          Fast
                                                                                         Mod.6327D : High speed
                                                                                         Mod.6327D : Low speed
Working                                                                                  Mod.6222D
speed

                          1                   2                                          3
                    Light                 Medium                                Heavy duty work
                    duty work             duty work
                                                        Load

                 Working speed                                           Performance examples
                                                                         one battery pack charge
  Numbers in chart below are relative values when setting Mod.6222D's capacity as 100.
  1 Light duty work
  Tightening screw
