T
ECHNICAL INFORMATION
Subject              Change of Chuck Ring
                                                                                                           63233


For Models           HM1202, HM1202C
Country              All countries
Description          Square grooves inside Chuck Ring has been eliminated as illustrated below.


                        New                                                              New




                               Square grooves                                                  No groove
                    Chuck Ring                                                  Chuck Ring
                    (324108-9)                                                  (324185-1)


Interchangeability(I/C)

 Item No.           Current part                Q'ty I/C            New part                     Q'ty      Note
              Chuck Ring                                    Chuck Ring                            1
008                                               1
              324108-9                                      324185-1

Note
Interchangeability mark ;      means that the new part is substituted for the current.

Implementation
HM1202 : From serial No.4806E (Feb., 2001)
HM1202C : From serial No.17347E (Feb., 2001)
