Image preview - the first page of the document

>> Download 6336D-TE documenatation <<

Text preview - extract from the document
       Models No.                 6336D/6316D
                                                                                                              New Tool

       Description             Cordless Driver Drill
  Model 6336D is the14.4V version of existing Model 6343D 18V
  Cordless Driver Drills with applying Aluminum gear housing.
  Model 6316D is the12V version.

    Model                Battery            Charger

   6336DWA         Battery 1422
   6336DWAE        Battery 1422 x 2 pcs
   6336DWB         Battery 1433
   6336DWBE        Battery 1433x 2 pcs
                                                                                                                      95 ")
    Model                Battery            Charger                                                                      3/4
   6316DWA         Battery 1222
   6316DWAE        Battery 1222 x 2 pcs
   6316DWB         Battery 1233
   6316DWBE        Battery 1233x 2 pcs
                                        6336DWBE                                6316DWA
    Motor                                        Direct current magnet motor
    Battery                 Battery 1422 NiCad 14.4V, 2.0Ah Battery 1222 NiCad 12V, 2.0Ah
                            Battery 1433 NiMH 14.4V, 2.2Ah Battery 1233 NiMH 12V, 2.2Ah
    Speed at no load                              High speed 0~1300 R/min
                                                     Low speed 0~400 R/min
    Chuck capacity                                    1.5(1/16") - 13(1/2")
    Drilling capacity                                 Iron works 13mm(1/2")
                              Wood works 36mm(1-7/16")              Wood works 30mm(1-3/16")
    Torque adjusting                            16 levels + Direct connection
    Max. tighten torque      48 N.m(390 kgf-cm,28ft
