Image preview - the first page of the document
6333D-TE


>> Download 6333D-TE documenatation <<

Text preview - extract from the document
 TECHNICAL INFORMATION                                                                                                Product

Models No.           6333D
Description          Cordless Driver Drills
                                                                                                 243 (9-9/16")
CONCEPTION AND MAIN APPLICATIONS




                                                                     241 (9-1/2")
      Model       Battery               Fast Charger
    6313DWAE Battery 1222 X2              DC1411
    6333DWA Battery 1422 Xl               DC1411
    6333DWAE Battery 1422 X2              DC1411                                                                      94
                                                                                                                         /16")
                                                                                                                   (3-11idth)
                                                                                                                     (w


                                                                                                   243 (9-9/16")




                                                                                246 (9-11/16")


                                                                                                                        94
                                                                                                                          /16")
  Specifications                                                                                                     (3-11 dth)
                                                                                                                       (wi
   Motor                6313DA       DC 12V magnet motor
                        6333DA       DC 14.4V magnet motor
   Battery              6313DA       Battery 1222(Ni-Cd,12V,2.0Ah)
                        6333DA       Battery 1422(NiCd,l4.4V,2.0Ah)
   No load speed        6313DA       H:0-1400rpm     L:0-450rpm
                        6333DA       H:0-l300rpm      L:0-400rpm
   Chuck capacity                    2.0-13mm(l/16-1/2")
   Max.drilling       Steel          l3mm(1/2")
   capacities         Wood           25.4mm(l")
   Setting off
                                     17 stages + drill-mode
   astening torque
   Max. fastening     6313DA         L:Approx.254Kgf.cm(18.4ft.lbs)
   torque             6333DA         L:Approx. 3l0Kgf.cm(22. 4ftlbs)
   (drill-mode)
   Declutching        6313DA         5-50Kgf..cm(0.4-3.6ft.1bs)
   torque             6333DA         10-60Kgf.cm(0.7-4. 3ft.lbs)
   Net weight         6313DA         2.0Kg(4.4lbs)
   (includingbattery) 6333DA         2.lKg(4.6lbs)
                                      L : Low speed      H : High speed
  Standard equipment
   +- Bit 2-45 --------------------- 2 pcs.   +- Bit 2-45 --------------------- 2 pcs.
   Battery Cover ------------------ 2 pcs.    Battery Cover ------------------ 2 pcs.
   Plastic Carrying Case--------- 1 pc.
                                              Plastic Carrying Case --------- 1 pc.

   The standard equipment for the tools shown may differ form country to country
Optional accessories
Drill Bit 1.5,2,3,4,5,6
Drill Bit for wood 9,12,15
Philips Bit l-65,2-45,2-65,2-ll0,2-150,2-250,3-45,3-65,3-ll0
Slotted Bit 5-45,5-82,6-70,6.35-45,8-45,8-70
Socket Bit 7-55,8-55,10-55
Foam Polishing Pad 125
Rubber Pad Assembly
Wool Bonnet 100
Fast Charger DC1410
High Capacity Battery 1222 (for 63l3DWAE)
High Capacity Battery 1422 (for 6333DWA,6333DWAE)


Features and benefits
See the attached sheet for more information.
                                                                   More endurable and longer life motor

    Handle shaped ergonomically and well balanced




        Push button for reversing
        direction of rotation
         can be actuated easily                                    Carbon brushes can be replaced easily.
         leaving the other hand free                               No need of dis-assembling housing




                                                                   Bit holder
                                                                    Bits can be held at
                                                                    both right and left sides.

                                                              New high capacity battery (2.0Ah)
                                                               can be removed easily by push button
New variable speed control switch
makes speed control easiest in the world.
 Widest areas of total stroke and stroke for variable speed
