Image preview - the first page of the document
63475-WW-1


>> Download 63475-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Torque Limiter Complete
                                                                                                             63475


For Models             HR3000C, HR3550C, HR4040C, HR4500C
Country                All countries
Description            Adhesive has been applied to Pin 4 in Torque Limiter Complete to prevent the Pin 4
                       from coming out of place.
                       Torque Limiter without Pin 4 may cause a Round Nut to rotate, resulting in the torque out of
                        presetting. To avoid such trouble, this addition of adhesive has been made. (However, Pin 4
                       in the Torque Limiter Complete which is installed on Rotary Hammers does not come out of
                       place. Accordingly, this change is applicable to Torque Limiter as a replacement part only.)

                                                                                    Adhesive applied to the Pin 4

                                        Torque Limiter Complete
                                        (Item No.104 of Parts List)




Note: Regarding Torque Limiter Complete as a replacement part                                   Round Nut
please check the Torque Limiter for Pin 4's presence.
When Pin 4 is not present, insert Pin 4 in the portion where
the notch on the Driving Nut of the Torque Limiter meets                 Pin 4
that of a Round Nut of the Torque Limiter as shown on right.
Caution: Be careful not to drop Pin 4 at the time of repairing.
Please use LOC TITE 603 (Part No. 045047-7A) as a adhesive.

                                                                  Driving Flange




Interchangeability(I/C)

  Item No.     Current part                         Q'ty I/C         New part                           Q'ty Note
 HR3000C, Torque Limiter Complete                             Torque Limiter Complete
                                                      1   Yes                                            1
 HR3550C: 151692-9                                            152955-6
       104
HR4040C: Torque Limiter Complete                                  Torque Limiter Complete
                                                      1   Yes                                            1
    084 150860-1                                                  159947-6
 HR4500C: Torque Limiter Complete                             Torque Limiter Complete
                                                      1   Yes 152954-8                                   1
     070 152763-5

 Implementation
Ready to your next order
