Image preview - the first page of the document
63421-WW-1


>> Download 63421-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject                        Change of Switch
                                                                                                                          63421
                                                                                                                        (Page 1 of 2)

                               4014NV, 4300BV, 4300SV, 4300V, 4301BV, 4301SV, 4301V, 6010BVR,
For Models
                               6510PBL, 8410BV, HR1820, HR1821, HR2220, HR2510, JV1600, M432
Country                        200V-240V countries
Description                    Switch has been changed as shown below.
 4014NV, 4300BV, 4300SV, 4300V, 4301BV, 4301SV, 4301V, 6010BVR, 6510PBL, 8410BV, M432

                                             Current                                                    New
 Cat. No.                                SGEL204CB                                              SGEL106CV-1A

                                                                         Power      Field
                                                                         supply
                                                                                                             C1
                                                                         cord                   M2
                                 1           4           5       3                              C2                M1
                                                                                            1            2
 Wiring
                                 2
                                                                                                                            Power
                Field                                                                                                       supply
                                                                                                                            cord

                                         Noise suppressor                                            Noise Suppressor
 HR1820, HR1821, HR2220, HR2510

                                             Current                                                   New
Cat. No.                                 SGE204CB                                               SGE106CV-1A

                                                                          Power     Field
                                                                          supply                             C1
                                                                          cord                  M2
                                     1           4           5       3                      1   C2                M1
                                                                                                         2
 Wiring
                                     2
                                                                                                                            Power
                       Field                                                                                                supply
                                                                                                                            cord

                                             Noise suppressor                                     Noise Suppressor

 JV1600

                                             Current                                                   New
Cat. No.                                 SGE204MB-1                                              SGE106CV-1P

                                                                                    Field
                                                                                                             C1
                                                                         To Power               M2
                                                                 2
                                                     C
                                         1




                                                                          supply            1   C2       2        M1
                                                     C

                                                                 4




                                                                           cord
                                         3




 Wiring
            To Field




                                                                                                                            Power
                                                                                                                            supply
                                                                                                                            cord


                                         Noise suppressor                                         Noise Suppressor
                                                                                               63421
                                                                                             (Page 2 of 2)
 Interchangeability(I/C)
 4014NV, 4300BV, 4300SV, 4300V, 4301BV, 4301SV, 4301V, 6010BVR, 6510PBL, 8410BV, M432
    Item No.         Current part              Q'ty I/C        New part                 Q'ty        Note
                Switch Assembly                         Switch
 See note below                                 1   Yes                                  1
                531013-5                                651256-4

  HR1820, HR1821, HR2220, HR2510
    Item No.        Current part               Q'ty I/C        New part                 Q'ty        Note
               Switch Assembly                          Switch
See note below                                  1   Yes                                  1
               531012-7                                 651258-0

   JV1600
    Item No.         Current part              Q'ty I/C        New part                Q'ty         Note
                                                        Switch
 See note below Switch                          1   Yes                                  1
                651865-9                                651919-2


 Note
Item Nos. for switch
Model    4014NV 4300BV 4300SV         4300V    4301BV 4301SV 4301V        6010BVR 6510PBL 8410BV
Item No.   023    060    007           046       069    045   068            013    039     032
Model    HR1820 HR1821 HR2220 HR2510 JV1600               M432
Item No.  083    083    058    093     043                046



 Implementation
4014NV: From serial No. 71214E (Feb.,2001)
4300BV: From serial No. 801923E (Feb.,2001)
6010BVR: From serial No. 211664E (Mar.,2001)
HR2510: From serial No. 61744E (Jun.,2001)
HR2220: To be informed later.
4300V: Discontinued since Apr.,1993
4300SV: Discontinued since Jun.,1991
4301V: Discontinued since Jul.,1988
4301BV: Discontinued since Aug.,1997
4301SV: Discontinued since Apr.,1993
6510PBL: Discontinued since Oct.,1993
8410BV: Discontinued since Apr.,1993
HR1820: Discontinued since May,1999
HR1821: Discontinued since Oct.,1993
JV1600: Discontinued since Oct.,1992
M432: Discontinued since Apr.,1993
