Image preview - the first page of the document
6343D-TE


>> Download 6343D-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
       Models No.               6343 D
                                                                                                              New Tool


       Description             18V Cordless Driver Drill
                                                                                                          )
                                                                                                    -1/16"
                                                                                              255(10
CONCEPTION AND MAIN APPLICATIONS
  18V Cordless driver drill developed as the highest class model in
  Cordless Driver Drills. The highest capacity and the fastest working
  speed are realized. With applying Aluminum gear housing and Side
  grip, it has become available for heavy load and the rigidity has been
  improved . 18 V Pushbutton type battery, Battery1822 (NiCad 2.0Ah)




                                                                              249(9-13/16")
  and 1833 (NiMH 2.2Ah) are applied.




     Model                Battery             Charger          Remarks
                                                                                                                      95 ")
    6343DWA         Battery 1822                                                                                         3/4
                                                                                                                     (3-
    6343DWAE        Battery 1822 x 2 pcs
                                               DC1801         For export
    6343DWB         Battery 1833
    6343DBE         Battery 1833x 2 pcs


  Specifications
    Motor                        Direct current magnet motor
    Battery                      Battery 1822 NiCad 18V, 2.0Ah
                                 Battery 1833 NiMH 18V, 2.2Ah
    Speed at no load             High speed 0~1400 R/min
                                 Low speed 0~450 R/min
    Chuck capacity               1.5(1/16") - 13(1/2")
    Drilling capacity            Iron works 13mm(1/2")
                                 Wood works 38mm(1-1/2")
    Torque adjusting             16 levels + Direct connection
    Max. tighten torque          45 N.m(450 kgf-cm,33ft
