Image preview - the first page of the document
63646-WW-1


>> Download 63646-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Housing, Set Plate, etc.
                                                                                                      63646
                                                                                                     (Page 1 of 2)


For Models           6095D

Country              European countries

Description          See below.
1. Housing without rubber has been replaced by one with rubber.
2. Set Plate with cushion has been replaced by one without cushion.
3. Pin 3 has been added.
4. Rubber Pin 6 has been added.
5. Makita Label has been added.
6. Pan Head Screws M4x22 (Item No. 001) have been replaced by Tapping Screws 4x18.
   Pan Head Screws M4x35 (Item No. 002) have been replaced by Tapping Screws 4x30.
7. Holder 6 has been eliminated.
8. Keyless Drill Chuck 10 has been changed.
Note: This Technical Information applies to machines manufactured in MME (Makita Manufacturing Europe Ltd.) only.


                     Current                                                      New
 Keyless Drill Chuck 10                                       Keyless Drill Chuck 10
                    Housing Set                                                 Housing Set
                          Pan Head Screw M4x35                                          Tapping Screw 4x30
                               Pan Head Screw M4x22                                          Tapping Screw 4x18


          Holder 6                                                                                 Makita Label




                                                                                                        Rubber

                                                                                   Rubber
Housing Set                                                Housing Set
                      Set Plate                                                    Set Plate




                         Cushion
                                                                                        Pin 3
                                                                         Rubber Pin 6
                                                                                                            63646
                                                                                                       (Page 2 of 2)

 Interchangeability(I/C)
Item No.   Current part                   Q'ty I/C        New part                       Q'ty          Note
   003 Housing Set                              No
                                                   Housing Set                            1
                                           1
   044 182803-5                                    183196-3
                                                   Pin 3
   049                                                                                    1
                                                   256158-5
                                                   Rubber Pin 6
   050                                                                                    2
                                                   263022-3
                                                   Makita Label
   051                                                                                    1
                                                   819063-3                                       Interchangeable
          Pan Head Screw M4x22                     Tapping Screw 4x18                                  as a set
   001                                     6    No                                        6
          911143-2                                 265995-6
          Pan Head Screw M4x35                     Tapping Screw 4x30
   002                                     2    No                                        2
          911163-6                                 266050-7
          Holder 6
   043                                     1
          411640-3
          Set Plate                                 Set Plate
   047                                     1    No                                        1
          163157-9                                  344549-3
          Keyless Drill Chuck 10           1        Keyless Drill Chuck 10
   008                                          Yes                                       1
          192016-0                                  763154-1


 Note
Use the Pt. No. 182141-5 instead of Pt. No. 182803-5 when you place an order for the current Housing Set.

 Implementation
From serial No. 543419G (Sep., 2000)
