Image preview - the first page of the document
63700-WW-1


>> Download 63700-WW-1 documenatation <<

Text preview - extract from the document
T ECHNICAL INFORMATION
 Subject                 Modification of Terminal
                                                                                                          63700

 For Models              BDF460, BHP460, BLS712, BLS820, BTD120, BTD150, BTD200, BTW120, BTW150,
                         BTW200, BTW201, DK2401, DK2403
 Country                 All countries
 Description             Terminal has been modified as illustrated below.


                 Model: BTD120


                                       (Switch)                   Current                             New

                                                        10.0mm(3/8")                  15.0mm(9/16")


 (Housing)


 (Receptacle)
                                                         1.5mm(1/16")                  2.5mm(3/32")

                                                                   Terminal                        Terminal
                                                                  (643955-2)                      (643983-7)




Interchangeability(I/C)

   Item No.         Current part                  Q'ty I/C          New part             Q'ty            Note
                Terminal                                      Terminal
See below.                                          1     Yes                             1
                643955-2                                      643983-7

Item No. of Terminal

 For Model BDF460 BHP460 BLS712 BLS820 BTD120 BTD150 BTD200 BTW120 BTW150 BTW200 BTW201
 Item No.           10                    8               47       8        16   47           8                16

For Model     DK2401      DK2403
 Item No.      ---          ---


 Implementation
BDF460: From serial No.5814E (Apr.,2001)
BHP460: From serial No.6713E (Apr.,2001)
BLS712: From serial No.1080E (Apr.,2001)
BLS820: To be informed later
BTD120: From serial No.1279E (Apr.,2001)
BTD150: From serial No.1049E (Apr.,2001)
BTD200: From serial No.4462E (Apr.,2001)
BTW120: From serial No.1297E (Apr.,2001)
BTW150: From serial No.1001E (Apr.,2001)
BTW200: From serial No.3973E (Apr.,2001)
BTW201: To be informed later
